Omron Power Relay, 24V DC Coil, 10A Switching Current, Double Pole Double Throw DPDT MKS2PN 24VDC
Specifications
| Country of Origin | India |
|---|---|
| Brand | Omron |
| Height | 34.5mm |
| Length | 34.5mm |
| Model | MKS2PN 24VDC |
| Width | 53.3mm |
| Contact Material | Silver Alloy |
| Series | MKS |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | Plug-In |
| Contact Resistance | 50mΩ |
| Standards/Approvals | UL, CSA |
| Coil Resistance | 430Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 250V |
| Coil Power | 1.4W |
| Switching Power | 1.4W |
Key Features
- Compact electromechanical power relay with a 24V DC coil for efficient control.
- Double Pole Double Throw (DPDT) contacts support switching of two independent circuits.
- Silver alloy contacts ensure low contact resistance of 50 milliohms for excellent conductivity.
- Rated switching current up to 10A suitable for moderate load control applications.
- Coil power consumption is low at 1.4W, optimizing energy efficiency.
- Wide operating temperature range from -40°C to 60°C to suit varied industrial environments.
- Plug-in terminal type enables quick installation and replacement in control panels.
- Meets UL and CSA safety standards ensuring compliance with North American regulations.
Product Description
Omron MKS2PN 24VDC Power Relay is a compact electromechanical switching device designed for control and automation tasks in industrial environments. It operates on a 24V DC coil voltage and offers a Double Pole Double Throw (DPDT) contact arrangement to switch two independent AC or DC circuits reliably.
This relay features silver alloy contacts providing a low contact resistance of 50 milliohms, ensuring efficient electrical performance. It is rated for a switching current of 10A, making it suitable for moderate load control such as in machinery and automation panels.
The coil power requirement is 1.4 watts with a coil resistance of 430 ohms, which helps minimize energy consumption during operation. The relay's robust design allows performing in a wide temperature range from -40°C to 60°C, accommodating installation in diverse industrial ambient conditions including cold storage.
Physical dimensions measuring 34.5 mm in height and length, with a width of 53.3 mm, make this relay compact and suitable for dense panel mounting where space is limited. The plug-in terminal design simplifies installation and maintenance, allowing easy relay replacement without rewiring.
Compact 24V DC coil power relay with DPDT contacts provides flexibility in routing circuits. Silver alloy contacts deliver low resistance for reliable switching performance. Rated for 10A switching currents attesting to moderate load handling capabilities.
Wide operational temperature range ensures suitability in varied industrial environments. Plug-in terminals facilitate straightforward installation and retrofit in control panels. Compliant with UL and CSA standards, supporting usage in regulated installations.
This power relay is well suited for use in industrial automation, control cabinets, signal routing applications, and electrical testing rigs. Its robust approvals and compact size make it an excellent component choice for reliable factory automation, machinery control, and retrofit replacements in modular control units.
Explore the wide range of Power Relay components at EnvMart designed to meet industrial automation and electrical system demands with high-quality, safety approvals, and trusted brand reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current rating of 10A, making it suitable for moderate load control applications.
This model operates on a coil voltage of 24V DC.
It features a Double Pole Double Throw (DPDT) contact configuration, allowing it to switch two independent circuits.
The contacts are made of silver alloy, which provides a low contact resistance of 50 milliohms for efficient conductivity.
The relay measures 34.5 mm in height and length, with a width of 53.3 mm, making it compact for panel mounting.
It has a wide operating temperature range from -40°C to 60°C, suitable for various industrial environments.
The coil power consumption is low at 1.4 watts, which helps optimize energy efficiency during operation.
It features a plug-in terminal type, allowing for quick installation and easy replacement without the need for rewiring.
The relay meets UL and CSA safety standards, ensuring compliance with North American regulations.
The coil resistance is 430 ohms, which is an important specification for its operation.
This power relay is well suited for industrial automation, control cabinets, signal routing applications, and electrical testing rigs.
The relay can switch DC voltages up to 250V.
