Bourns Shielded Wirewound Surface Mount Inductor 1 μH ±20 % 18 A Idc Carbonyl Powder Core SRP1038A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 3.8mm |
| Length | 11mm |
| Model | SRP1038A |
| Depth | 10mm |
| Packaging | Reel |
| Series | SRP1038A |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Carbonyl Powder |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | 1038 |
| Maximum DC Current | 18A |
| Pin Count | 2 |
| Maximum DC Resistance | 3.3mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 47MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a carbonyl powder core for high saturation current.
- Features AEC-Q200 automotive standard compliance for reliability.
- Offers ±20 % inductance tolerance ensuring consistent performance.
- Maximum DC resistance of 3.3 mΩ minimizes power loss.
- Designed with magnetic shielding to reduce interference.
- Rated for operating temperatures from -40°C to 150°C.
- Maximum self-resonant frequency of 47 MHz for high-frequency applications.
- Solder termination style and 2 pin count for easy PCB integration.
Product Description
Bourns SRP1038A shielded wirewound Surface Mount Inductor is engineered for high current applications requiring robust performance and compact size. Featuring a carbonyl powder core, this inductor delivers a 1 μH inductance with a ±20 % tolerance and supports a maximum DC current of 18 A, making it suitable for demanding automotive and industrial electronic systems.
This series adheres to the stringent AEC-Q200 automotive standard, optimizing reliability in vehicular environments including driver assistance, entertainment, and lighting circuits. The magnetic shielding design reduces electromagnetic interference, ensuring signal integrity in sensitive applications.
The SRP1038A model has a maximum DC resistance of 3.3 mΩ and can operate efficiently within a temperature range from -40°C to 150°C. Its solder termination style and 2-pin configuration provide easy surface mount assembly on printed circuit boards. The compact form factor with dimensions of 11 mm length, 3.8 mm height, and 10 mm depth facilitates integration in space-constrained devices.
The maximum self-resonant frequency of 47 MHz and a minimum quality factor of 20 support high-frequency circuit requirements. Molded construction and wirewound design enhance mechanical durability and performance consistency.
Applications include automotive electronic subsystems, DC/DC power converters, and varied power supply circuits. The reel packaging ensures efficient automated insertion during production.
Constructed with a carbonyl powder core for high saturation current. Compliant with AEC-Q200 automotive reliability standards. Features magnetic shielding to minimize electromagnetic interference. Compact size and solder termination style for surface mount assembly.
Supports 1 μH inductance with ±20 % tolerance and 18 A DC current. Wide operating temperature range from -40°C to 150°C. Maximum DC resistance of 3.3 mΩ for efficient power use. High self-resonant frequency of 47 MHz ideal for high-frequency designs.
Molded wirewound construction ensures durability and consistent operation. Suitable for automotive, power supply, and DC/DC converter applications. Explore the Bourns range on EnvMart to find high-quality inductors and electronic components tailored for both industrial and automotive needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRP1038A inductor has an inductance value of 1 μH with a tolerance of ±20%.
This model supports a maximum DC current of 18 A, making it suitable for high current applications.
The maximum DC resistance of the SRP1038A is 3.3 mΩ, which helps minimize power loss during operation.
It can operate efficiently within a temperature range from -40°C to 150°C.
The maximum self-resonant frequency of the SRP1038A is 47 MHz, making it suitable for high-frequency applications.
The inductor is constructed with a carbonyl powder core, which allows for high saturation current.
This model features a solder termination style and has a 2-pin configuration for easy surface mount assembly.
The SRP1038A complies with the AEC-Q200 automotive standard, ensuring reliability in vehicular applications.
The dimensions of the SRP1038A are 11 mm in length, 3.8 mm in height, and 10 mm in depth.
This inductor is suitable for automotive electronic subsystems, DC/DC power converters, and various power supply circuits.
The SRP1038A is packaged on a reel, which facilitates efficient automated insertion during production.
The minimum quality factor of this model is 20, supporting its performance in high-frequency circuits.
