Schneider Electric Contactor, LC1D258FD, 110V AC Coil, 4-Pole, 40A, 110V DC Control, 2 NO/2 NC, 690V AC
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Length | 45mm |
| Model | LC1D258FD |
| Depth | 107mm |
| Width | 91mm |
| Mount Type | DIN Rail |
| Series | LC1D |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw |
| Number of Poles | 4 |
| Contact Voltage | 690V ac |
| Coil Voltage | 110V ac |
| Normal State Configuration | 2 NO/2 NC |
| Better World Claim | Designed for Disassembly |
| Contact Current | 40A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Control Circuit Voltage Uc | 110V dc |
| Pole and Throw Configuration | 4 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Equipped with a 110V AC coil voltage suitable for numerous industrial control systems.
- 4 poles configured with 2 normally open and 2 normally closed auxiliary contacts for versatile switching.
- Rated for a contact voltage of up to 690V AC and a contact current of 40A.
- Constructed for DIN rail mounting with screw-type terminals and IP20 finger-safe protection.
- Operates reliably between -5°C and 60°C ambient temperatures, ensuring durable performance.
- Includes built-in auxiliary contacts and flexible control circuits for varied applications.
- Designed for easy installation and quick setup in motor starters and control panels.
- Compliant with multiple international standards including EN 60947 and UL certifications.
Product Description
Schneider Electric LC1D258FD is a high-quality TeSys D Contactor designed for industrial automation and control systems. Featuring a 110V AC coil and a 4-pole design capable of handling 40A contact current at 690V AC, this contactor is suitable for motor starters and diverse loads.
The contactor is equipped with 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, utilizing screw terminals for reliable and secure connections. It mounts easily on DIN rails or panels, providing IP20 finger-safe terminals with clear international markings.
Operational over a temperature range from -5°C to 60°C, it offers dependable switching performance for heating, resistive loads, and motor control under AC-1 and AC-3 utilization categories. The contactor’s flexible control circuitry supports a wide range of industrial applications.
110V AC coil voltage suitable for varied control circuits. 4-pole configuration with 2 NO/2 NC auxiliary contacts. Contact voltage rating of 690V AC and contact current of 40A. DIN rail mounting and screw terminal type for sturdy installation.
Operates reliably between -5°C to 60°C ambient temperatures. Complies with EN 60947-4-1, IEC 60947, UL, CSA, and other international standards. IP20 finger-safe terminals with both North American and International markings.
Designed for sustainable use with a Better World claim of being designed for disassembly.
This contactor is ideal for industrial, manufacturing, HVAC, and automation applications, facilitating motor control, switching, and power management tasks. Explore more Schneider Electric products in the Contactors category at EnvMart for reliable industrial automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC1D258FD contactor has a contact current rating of 40A.
This model operates with a coil voltage of 110V AC.
The maximum contact voltage for this contactor is 690V AC.
The LC1D258FD contactor is designed with 4 poles.
It operates reliably within a temperature range of -5°C to 60°C.
This contactor is designed for DIN rail mounting.
The contactor features 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts.
The dimensions of this model are 45mm in length, 91mm in width, and 107mm in depth.
It uses screw-type terminals with IP20 finger-safe protection.
This contactor complies with EN 60947-4-1, IEC 60947, UL, and CSA standards.
It is suitable for motor control, switching, and power management tasks in industrial automation, HVAC, and manufacturing applications.
The contactor is designed for disassembly, aligning with sustainability goals.
