Hirose Mini-Fit Sr Series Right Angle Through Hole PCB Header, 5 Contacts, 10 mm Pitch, 1 Row, Shrouded 42820-5213

Molex 42820-5213 Mini-Fit Sr Series Right Angle Through Hole PCB Header is a high-quality, reliable wire-to-board connector designed for industrial, commercial, and electronic applications. This connector features 5 gold-plated brass male contacts arranged in a single row with a 10 mm pitch, providing a stable and efficient electrical interface.

The shrouded design adds mechanical protection and ensures proper mating. It has a thermoplastic housing delivering robust insulation and durability in assorted environmental conditions. Rated for 600V voltage and 50A current, it is capable of supporting demanding power loads in industrial and laboratory settings.

The through-hole mount style provides secure attachment to printed circuit boards, with a minimum operating temperature of -40°C and maximum operating temperature of 105°C, making it suitable for wide temperature range applications. The inclusion of pre-assembled male contacts and metal retention clips facilitates easy mounting and reliable performance.

This Mini-Fit Sr Series connector is ideal for power distribution in electrical equipment, industrial machinery, and consumer electronics. It supports wire-to-board connectivity where secure and high-current connections are required.

Designed for wire-to-board applications ensuring reliable electrical connections. Features gold-plated brass contacts for excellent conductivity and corrosion resistance. Mount type is through hole providing stable mechanical mounting on PCB.

Operates between -40°C to 105°C, suitable for demanding environments. Supports a voltage rating of 600V and current capacity up to 50A. Constructed with durable thermoplastic housing for insulation and protection. Pre-assembled male contacts and metal PCB retention clips enhance assembly efficiency.

Compact 1 row, 10 mm pitch layout optimizes space on circuit boards. Shrouded connector ensures secure mating and protection against misalignment.

This product is manufactured to high standards suitable for use in industrial, laboratory, and commercial electrical assemblies. For more options in PCB Headers and connectors, browse the Electronics Components category at EnvMart.
