Eaton xEffect Miniature Circuit Breaker, 2-Pole, 10A, Type C Tripping, 400V AC, 6 kA Breaking Capacity FAZ6

Eaton FAZ6 Miniature Circuit Breaker, Model FAZ6-C10/1N, is a high-quality 2-pole circuit breaker rated at 10 amperes, designed for 400V AC electrical systems. It combines thermal and electromagnetic release mechanisms to provide efficient protection against overloads and short circuits, with a breaking capacity of 6 kA. The compact design, with a module width of 17.5 mm per pole, facilitates easy installation on DIN rails in electrical distribution boards, control panels, and various industrial and commercial applications.

The FAZ6 series is engineered for fast short-circuit interruption, significantly reducing let-through energy to prevent damage to wiring and connected equipment. Its thermal-magnetic tripping characteristics feature a Type C trip curve, which activates at 5 to 10 times the rated current, ideal for circuits with moderate inrush currents such as motors, lighting, and transformers.

The toggle switch provides clear indication of switch position, while the device’s trip-free mechanism ensures that the breaker cannot be held in the ON position against a fault condition, enhancing operator safety. The enclosure is finger-proof (IP20), protecting users from accidental contact with live components. Mounting is simplified by a standard DIN rail interface and a 3-position rail clip for secure attachment.

Rated current of 10A with Type C instantaneous trip. Breaking capacity of 6 kA suitable for industrial and commercial use. Dual thermal and magnetic release mechanism for reliable protection. Compact 35 mm width for 2 poles reduces panel space requirements.

Toggle switch with front contact position indication. Finger-proof design and trip-free mechanism improve safety. Compliance with IEC 60947-2, IEC 898, and EN standards. DIN rail mounting with easy installation and secure fit.

IP20 protection rating for safe operation in enclosed panels. Applicable in residential, industrial, and commercial electrical distribution.

This Eaton xEffect FAZ6 Miniature Circuit Breaker is suited for protecting electrical systems in HVAC, manufacturing, water treatment, and general automation. It ensures circuit integrity while minimizing downtime and electrical hazards. EnvMart offers this reliable Eaton MCB as part of its comprehensive industrial electrical protection components catalogue.
