Texas Instruments Instrumentation Amplifier 1 mV Offset 18 MHz 14-Pin SOIC 880 μA LM6144BIM/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.499mm |
| Length | 8.74mm |
| Model | LM6144BIM/NOPB |
| Mount Type | Surface |
| Series | LM6144 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 24V |
| Minimum Supply Voltage | 1.8V |
| Supply Current | 880μA |
| GBP - Gain Bandwidth Product | 18MHz |
| Vos - Input Offset Voltage | 1 mV |
| Slew Rate | 13V/μs |
| CMRR - Common Mode Rejection Ratio | 107dB |
Key Features
- This amplifier features a low input offset voltage of 1 mV ensuring high precision operation.
- Operating frequency bandwidth reaches up to 18 MHz for fast signal processing.
- It comes in a 14-pin SOIC surface mount package suitable for compact PCB designs.
- The device operates with a supply voltage range from 1.8V to 24V.
- It consumes a low supply current of 880 μA for energy-efficient applications.
- Offers a high common mode rejection ratio (CMRR) of 107 dB, reducing noise interference.
- Can operate reliably in temperatures ranging from -40°C to 85°C, suitable for industrial environments.
- Comes in a quad channel configuration with 4 channels per device.
Product Description
Texas Instruments LM6144BIM/NOPB Instrumentation Amplifier is a high-speed operational amplifier designed for precise signal amplification in various electronic systems. Featuring a low input offset voltage of 1 mV and a gain bandwidth product of 18 MHz, this device ensures accurate amplification of small differential signals.
Encapsulated in a 14-pin SOIC surface mount package, the LM6144BIM/NOPB is optimized for space-saving PCB layouts and is ideal for instrumentation, medical equipment, and industrial process control applications.
This instrumentation amplifier operates over a supply voltage range from 1.8V to 24V and draws a modest supply current of 880 μA, allowing efficient power consumption for portable and embedded systems. Its high common mode rejection ratio of 107 dB effectively minimizes noise and interference, supporting high-fidelity signal processing.
The device accommodates a wide operating temperature range from -40°C to 85°C to withstand harsh environments, making it suitable for automotive and industrial applications where reliability is critical.
Low input offset voltage of 1 mV for precision amplification. High gain bandwidth product of 18 MHz supports high-frequency signal processing. Compact 14-pin SOIC package for easy surface mounting. Wide supply voltage range from 1.8V to 24V ensuring flexibility.
Low supply current of 880 μA for energy-efficient operation. Exceptional CMRR of 107 dB reduces noise and interference. Wide operating temperature range from -40°C to 85°C for industrial usage. Quad channel amplifier suitable for multi-channel instrumentation.
This amplifier is widely used in industrial, laboratory, medical instrumentation, data acquisition systems, and communications equipment where high accuracy and low noise are mandatory.
Explore more Texas Instruments products and Instrumentation Amplifiers on EnvMart for reliable and high-performance electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product (GBP) of the LM6144BIM/NOPB is 18 MHz, supporting high-frequency signal processing.
It features a low input offset voltage of 1 mV, ensuring high precision operation.
This instrumentation amplifier operates over a supply voltage range from 1.8V to 24V.
This model is a quad channel amplifier, providing 4 channels per device.
The maximum operating temperature for the LM6144BIM/NOPB is 85°C, suitable for industrial environments.
It has a high common mode rejection ratio (CMRR) of 107 dB, which reduces noise interference.
This amplifier consumes a low supply current of 880 μA, making it energy-efficient for various applications.
The dimensions of this model are 8.74 mm in length and 1.499 mm in height.
It comes in a surface mount package, specifically in a 14-pin SOIC configuration.
The minimum operating temperature for the LM6144BIM/NOPB is -40°C, allowing it to function in harsh conditions.
The slew rate of this instrumentation amplifier is 13 V/μs, which supports rapid signal changes.
This amplifier is commonly used in industrial, laboratory, medical instrumentation, data acquisition systems, and communications equipment.
