Schneider Electric LC1K0601U7 TeSys K Contactor, 230V AC Coil, 3-Pole, 6A, 1.5 kW 240V, 3 NO, 690V AC LC1K0601U7
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 58mm |
| Model | LC1K0601U7 |
| Depth | 57mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1K |
| Power Rating | 1.5kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | CSA, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 6A |
| Number of Auxiliary Contacts | 1 |
| Auxiliary Contact Configuration | 1 NC |
| Operational Current Ie | 6A |
| Control Circuit Voltage Uc | 240V |
| Contactor Application | Resistive Load |
| Pole and Throw Configuration | 3P |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Compact 3-pole contactor rated for 6A operational current.
- Power rating of 1.5 kW at 240V AC suitable for resistive load control.
- Includes 3 Normally Open (NO) contacts and 1 Normally Closed (NC) auxiliary contact.
- Compatible with 240V control circuit voltage and designed for 50/60 Hz operation.
- Operating temperature range from -25°C to 50°C for robust performance.
- Complies with CSA and UL standards ensuring high safety and quality.
- Optimized for simple motor and resistive load switching applications.
- Designed for easy installation and disassembly with Better World product certification.
Product Description
Schneider Electric LC1K0601U7 is a compact and reliable 3-pole TeSys K contactor designed specifically for motor control and resistive load applications. It features a coil voltage of 230V AC and is rated for an operational current of 6A, supporting power loads up to 1.5 kW at 240V AC.
This contactor includes three Normally Open (NO) main contacts and one built-in Normally Closed (NC) auxiliary contact, offering flexible control circuit configurations. The DIN Rail mounting type and screw clamp terminals facilitate easy installation and wiring in industrial and commercial electrical panels.
The control circuit voltage is 240V compatible, operating efficiently at both 50 Hz and 60 Hz frequencies, making it suitable for a wide range of electrical systems. The contactor is optimized for simple power applications such as motor starting, air conditioning systems, pumps, and compressors.
Operating reliably in temperatures ranging from -25°C to 50°C, it ensures consistent performance in demanding environments. Its compact dimensions (58mm length × 45mm width × 57mm depth) allow integration into tight installation spaces.
Schneider Electric LC1K0601U7 meets international standards including CSA and UL, providing assurance of safety and quality. It is also recognized as a Better World product for designed disassembly, supporting sustainability efforts.
Compact 3-pole motor contactor rated 6A and 1.5 kW. 230V AC coil voltage with screw clamp terminal connections. Includes 3 NO main contacts and 1 NC auxiliary contact. DIN Rail mounting compatible and panel mountable. Temperature range from -25°C to 50°C for durability.
Complies with CSA and UL safety standards. Suitable for resistive load and motor control applications. Designed for easy installation and maintenance. Recognized as a Better World product for sustainability. Optimized for simple power devices such as pumps and compressors.
This Schneider Electric contactor is ideal for industrial, manufacturing, HVAC, and automation applications requiring reliable switching of motors and resistive loads. The product is suitable for use in both commercial and industrial electrical circuits, offering robust control and energy efficiency. Explore more Schneider Electric Contactors and auxiliary contacts on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC1K0601U7 contactor has an operational current rating of 6A.
It has a power rating of 1.5 kW at 240V AC, suitable for resistive load control.
The coil voltage for this contactor is 230V AC.
This model features a 3-pole configuration.
The contactor measures 58mm in length, 45mm in width, and 57mm in depth.
It operates reliably within a temperature range of -25°C to 50°C.
The LC1K0601U7 is designed for DIN Rail mounting.
It includes three Normally Open (NO) contacts and one Normally Closed (NC) auxiliary contact.
It complies with CSA and UL standards, ensuring safety and quality.
This model is optimized for simple motor control and resistive load applications, such as pumps and compressors.
The LC1K0601U7 features screw clamp terminals for easy wiring.
The maximum contact voltage is 690V AC.
