Weidmüller OMNIMATE SL Series Pluggable Terminal Block 12-Contact 5.08 mm Pitch 1 Row 400V 18A Solder Male Right 1154880000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Orange |
| Orientation | Right Angle |
| Current | 18A |
| Length | 11.63mm |
| Depth | 12mm |
| Width | 62.72mm |
| Housing Material | Polybutylene Terephthalate |
| Series | OMNIMATE SL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | IEC 61984, IEC 60664-1 |
| Number of Contacts | 12 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- Supports 18A current rating for robust electrical applications.
- Constructed with Polybutylene Terephthalate housing for durability.
- Features solder wire connection method and male connector gender.
- Designed with right-angle orientation for space-efficient mounting.
- Rated for up to 400V voltage for versatile usage.
- Complies with IEC 61984 and IEC 60664-1 standards ensuring safety and quality.
- Compact size with 62.72 mm width, 11.63 mm length, and 12 mm depth.
- Made in Germany, ensuring premium manufacturing quality.
Product Description
Weidmüller 1154880000 OMNIMATE SL Series Pluggable Terminal Block features a 12-contact design with a 5.08 mm pitch and a single row, making it ideal for precise and secure PCB connectivity in industrial and electronic applications. This component supports a current rating of 18A and a voltage rating of 400V, enabling its use in a variety of high-demand electrical installations.
The terminal block is manufactured using durable Polybutylene Terephthalate housing material, which ensures long-term reliability and resistance to environmental stress. The male connector with right-angle orientation optimizes PCB space and facilitates straightforward cable connections through soldering techniques.
This terminal block is compliant with IEC 61984 and IEC 60664-1 standards, ensuring adherence to international safety and quality norms. Its dimensions (62.72 mm width, 11.63 mm length, and 12 mm depth) suit various compact assembly requirements.
Designed and manufactured in Germany, this product upholds stringent quality assurance. The OMNIMATE SL series utilizes advanced pin technology with 3.2 mm pin length optimized for wave soldering, providing reliable and efficient electrical connections.
The product is widely applicable in electronic manufacturing, industrial automation, laboratory equipment, HVAC systems, and other fields requiring durable and precise electrical termination solutions.
Supports 18A current rating for robust electrical applications. Constructed with Polybutylene Terephthalate housing for durability. Features solder wire connection method and male connector gender. Designed with right-angle orientation for space-efficient mounting.
Rated for up to 400V voltage for versatile usage. Complies with IEC 61984 and IEC 60664-1 standards ensuring safety and quality. Compact size with 62.72 mm width, 11.63 mm length, and 12 mm depth. Made in Germany, ensuring premium manufacturing quality.
Explore the full Weidmüller OMNIMATE SL series and other Pluggable Terminal Blocks on EnvMart for reliable and high-quality electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block supports a current rating of 18A, making it suitable for robust electrical applications.
It is rated for up to 400V, allowing for versatile usage in various electrical installations.
The terminal block has a width of 62.72 mm, a length of 11.63 mm, and a depth of 12 mm, making it compact for assembly requirements.
The housing is constructed from Polybutylene Terephthalate, which provides durability and resistance to environmental stress.
This model features a 12-contact design, facilitating secure PCB connectivity.
It features a solder wire connection method, allowing for straightforward cable connections.
The connector is designed with a right-angle orientation, optimizing PCB space for installation.
It complies with IEC 61984 and IEC 60664-1 standards, ensuring adherence to international safety and quality norms.
The pitch size is 5.08 mm, which is standard for pluggable terminal blocks in various applications.
This terminal block is made in Germany, ensuring premium manufacturing quality.
It is widely applicable in electronic manufacturing, industrial automation, laboratory equipment, and HVAC systems.
The connector gender is male, which is typical for this type of terminal block.
