STMicroelectronics Voltage Output Temperature Sensor Series, Analogue, Through Hole Mount, ±1°C Accuracy, 3-Pin MCP9509CT
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±1°C |
| Brand | STMicroelectronics |
| Height | 5mm |
| Length | 5mm |
| Model | MCP9509CT |
| Width | 4mm |
| Mount Type | Through Hole |
| Output type | Voltage |
| Series | MCP9509CT |
| Maximum Operating Temperature | 100°C |
| Package Type | TO-92 |
| Sub Type | Temperature Sensor |
| Minimum Operating Temperature | -40°C |
| Interface Type | Analogue |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Supply Voltage | 3.91V |
| Minimum Supply Voltage | 2.95V |
| Sensor Gain | 10mV/K |
Key Features
- Provides linear voltage output proportional to absolute temperature.
- Operates over a temperature range of -40°C to 100°C.
- Requires supply voltage between 2.95V and 3.91V for optimal function.
- Features a sensor gain of 10mV/K for precise temperature measurements.
- Compact TO-92 package with dimensions 5mm height, 5mm length, and 4mm width.
- Suitable for various industrial and laboratory temperature sensing applications.
- Compliant with RoHS environmental standards ensuring safe usage.
- Designed for through-hole mounting facilitating easy PCB integration.
Product Description
STMicroelectronics MCP9509CT Series voltage output temperature sensor provides accurate temperature sensing with an analogue voltage output proportional to absolute temperature. The sensor features ±1°C accuracy and is designed for reliable operation within a temperature range of -40°C to 100°C, making it suitable for a wide range of industrial, laboratory, and manufacturing applications.
This Temperature Sensor operates with a supply voltage ranging from 2.95V to 3.91V and delivers a sensor gain of 10mV/K. Housed in a compact 3-pin TO-92 package, measuring 5mm in height, 5mm in length, and 4mm in width, the sensor is optimized for through-hole mounting on printed circuit boards.
The LM235/LM335 family to which this sensor belongs functions as two-terminal zeners with linear output voltage that corresponds directly to absolute temperature, simplifying interfacing with analogue measurement systems. The device complies with RoHS standards, ensuring environmental safety and compatibility with modern electronics manufacturing processes.
This sensor is ideal for applications requiring precise temperature monitoring and control in environments such as industrial machinery, HVAC systems, water treatment plants, and scientific instrumentation.
Provides linear voltage output proportional to absolute temperature. Operates over a temperature range of -40°C to 100°C. Requires supply voltage between 2.95V and 3.91V for optimal function. Features a sensor gain of 10mV/K for precise temperature measurements.
Compact TO-92 package with dimensions 5mm height, 5mm length, and 4mm width. Suitable for various industrial and laboratory temperature sensing applications. Compliant with RoHS environmental standards ensuring safe usage.
Designed for through-hole mounting facilitating easy PCB integration.
For professional industrial temperature sensing requirements, explore environmental sensors at EnvMart to find compatible products and accessories tailored to your technical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This temperature sensor operates over a range of -40°C to 100°C.
The MCP9509CT features an accuracy of ±1°C.
It has a sensor gain of 10mV/K, providing precise temperature measurements.
This model provides a linear voltage output proportional to absolute temperature.
The sensor is housed in a TO-92 package with dimensions of 5mm in height, 5mm in length, and 4mm in width.
It requires a supply voltage between 2.95V and 3.91V for optimal operation.
This model is designed for through-hole mounting, facilitating easy integration onto printed circuit boards.
It complies with RoHS environmental standards, ensuring safe usage.
This temperature sensor has a pin count of 3.
It is suitable for various industrial and laboratory temperature sensing applications, including HVAC systems and scientific instrumentation.
The sensor uses an analogue interface for output.
The country of origin for this model is India.
