TE Connectivity Buchanan Series Pluggable Terminal Block 3-Contact 5.08 mm Pitch 1 Row Polyamide Housing 15A 300V AC 282807-3
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 300V ac |
| Brand | TE Connectivity |
| Colour | Green |
| Orientation | Right Angle |
| Current | 15A |
| Length | 15.24mm |
| Model | 282807-3 |
| Depth | 15.5mm |
| Width | 18.4mm |
| Housing Material | Polyamide |
| Series | Buchanan |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | EU RoHS, EU REACH, EU ELV, CHINA RoHS |
| Number of Contacts | 3 |
| Connector Gender | Male |
| Minimum Wire Size AWG | 12AWG |
| Maximum Wire Size AWG | 30AWG |
Key Features
- The terminal block supports current load up to 15 amperes.
- Constructed with green polyamide housing ensuring durability and insulation.
- Designed with right-angle orientation suited for PCB side stacking applications.
- Compatible with wire sizes from 12 AWG to 30 AWG for versatile connectivity.
- Rated for 300 volts AC operating voltage for safe electrical performance.
- Includes retention latches and polarization key slots for secure and error-free installation.
- Manufactured in Germany according to strict quality standards.
- Meets EU RoHS, REACH, ELV and China RoHS environmental compliance mandates.
Product Description
TE Connectivity 282807-3 Buchanan Series Pluggable Terminal Block is engineered for reliable industrial, manufacturing, and electrical PCB assembly applications. Featuring a 3-contact design with a 5.08 mm pitch arranged in a single row, it offers optimal connection density and electrical performance.
The housing is made from robust green polyamide 6.6 GF material offering excellent mechanical stability, thermal resistance, and electrical insulation, suitable for demanding environments.
Current rating is 15 amperes with voltage handling up to 300 volts AC, making it ideal for control panels, automation systems, and power distribution assemblies. Wire size compatibility from 12 AWG down to 30 AWG enables flexible conductor choices depending on circuit requirements.
Designed with a right angle orientation and side stackable layout, it simplifies PCB layout and enables compact stacking with mating header connectors. Retention latches and polarization keys ensure secure mating and prevent incorrect connections.
Manufactured in Germany, this terminal block meets international environmental and safety standards such as EU RoHS, REACH, ELV, and China RoHS, reflecting TE Connectivity's commitment to quality and sustainability.
The terminal block supports current load up to 15 amperes. Constructed with green polyamide housing ensuring durability and insulation. Designed with right-angle orientation suited for PCB side stacking applications. Compatible with wire sizes from 12 AWG to 30 AWG for versatile connectivity.
Rated for 300 volts AC operating voltage for safe electrical performance. Includes retention latches and polarization key slots for secure and error-free installation. Manufactured in Germany according to strict quality standards.
Meets EU RoHS, REACH, ELV and China RoHS environmental compliance mandates. Fits typical header stocks such as RS stock number 710-0110.
This TE Connectivity Buchanan terminal block is suitable for electronics manufacturing, industrial control systems, HVAC units, and other electrical assemblies requiring reliable pluggable terminal solutions. Browse EnvMart's extensive catalog for additional TE Connectivity components and Pluggable Terminal Blocks.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block is rated for a current load of up to 15 amperes.
It is rated for an operating voltage of 300 volts AC.
This terminal block is compatible with wire sizes ranging from 12 AWG to 30 AWG.
The contact pitch of this terminal block is 5.08 mm.
It features a right-angle orientation, making it suitable for PCB side stacking applications.
The housing is constructed from green polyamide 6.6 GF material, providing excellent mechanical stability and electrical insulation.
This model has 3 contacts.
The dimensions are approximately 15.24 mm in length, 15.5 mm in depth, and 18.4 mm in width.
It meets EU RoHS, REACH, ELV, and China RoHS environmental compliance mandates.
This terminal block is manufactured in Germany according to strict quality standards.
It includes retention latches and polarization key slots to ensure secure mating and prevent incorrect connections.
It is suitable for electronics manufacturing, industrial control systems, HVAC units, and other electrical assemblies requiring reliable pluggable terminal solutions.
