Preci-Dip 350 Series Straight Surface Pin Header 8 Contacts 2.54 mm Pitch 1 Row Unshrouded 350-80-108-00-106191
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | 350 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- The pin header features a low-profile design with a 2.54 mm pitch for precise electronic integration.
- Constructed from liquid crystal polymer housing providing excellent durability and resistance.
- Contacts are made of copper alloy plated with tin to ensure reliable conductivity and corrosion resistance.
- Suitable for surface mounting with a straight orientation and unshrouded connector configuration.
- Rated for 3A current and operating voltages up to 150V.
- Designed to withstand operating temperatures from -55°C to 125°C.
- Compatible with solder termination for secure PCB assembly.
- Manufactured in Switzerland with high-quality Swiss engineering standards.
Product Description
Preci-Dip 350-80-108-00-106191 is a high-quality straight surface mount pin header designed for electronic applications requiring robust board-to-board connections. It features 8 male contacts arranged in a single row with a precise 2.54 mm pitch, ideal for compact electronic assemblies and low-profile integration.
The pin header housing is made from liquid crystal polymer, which offers excellent mechanical strength, heat resistance, and durability in demanding industrial environments. The contacts are fabricated from copper alloy and plated with tin to provide reliable electrical conductivity and resistance to corrosion over prolonged use.
This component supports a current rating of 3A and can safely operate at voltages up to 150V, making it suitable for a variety of electronic circuitry applications including communication devices, industrial controls, and embedded systems.
With a minimum operating temperature of -55°C and maximum operating temperature of 125°C, it is engineered to perform reliably in extreme temperature conditions found in industrial, manufacturing, and automotive environments.
The connector is unshrouded and features a straight orientation optimized for surface mounting on printed circuit boards using solder termination, ensuring secure and stable mechanical and electrical connections.
The pin header is ideal for use in industrial, manufacturing, electronic prototyping, and laboratory equipment applications. It is manufactured in Switzerland, guaranteeing high precision and quality in line with Swiss engineering standards.
This product is categorized under PCB Pin Headers, essential components for advanced electronic circuit design and manufacturing processes.
For engineers and designers seeking precision and reliability in board-to-board connector solutions, the Preci-Dip 350 Series pin header offers a robust and proven choice. Browse the Electronics Components category at EnvMart for more PCB connector options and technical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm, which is designed for precise electronic integration.
This model features 8 male contacts arranged in a single row.
It is rated for a maximum operating voltage of 150V.
The pin header has a current rating of 3A.
The housing is made from liquid crystal polymer, while the contacts are made of copper alloy plated with tin for conductivity and corrosion resistance.
It can operate in temperatures ranging from -55°C to 125°C.
This unit uses solder termination for secure PCB assembly.
The connector is unshrouded, which is optimized for surface mounting.
It is manufactured in Switzerland, adhering to high-quality Swiss engineering standards.
This model is designed for surface mounting on printed circuit boards.
It is suitable for various electronic circuitry applications including communication devices, industrial controls, and embedded systems.
This pin header has 1 row of contacts.
