Preci-Dip 803 Series Straight Surface PCB Socket, 6-Contact, 2 Row, 2.54 mm Pitch 803-87-006-10-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Surface |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- This socket features a 2.54 mm pitch for standard PCB layouts.
- It supports a maximum current of 12A and voltage rating of 150V.
- The housing is made of black glass filled polyester ensuring durability.
- Surface mount type with straight orientation allows easy PCB assembly.
- Contacts are made of beryllium copper alloy plated with gold flash for excellent conductivity.
- Designed for operating temperatures from -55°C to 125°C, suitable for various environments.
- Connector system is board-to-board with female contact gender.
Product Description
Preci-Dip 803-87-006-10-001101 Straight Surface PCB Socket is a robust and precise connector designed for board-to-board applications. Featuring 6 contacts arranged in 2 rows with a standardized 2.54 mm pitch, this socket supports electrical currents up to 12A and voltages of 150V.
The connector’s housing is constructed from black glass filled polyester, ensuring mechanical strength and resistance to wear. The contacts utilize a beryllium copper alloy with a protective gold flash plating, providing excellent electrical conductivity and corrosion resistance. Its surface mount technology and straight orientation facilitate efficient soldering on PCB surfaces.
Rated for a temperature range from -55°C to 125°C, this PCB socket is suitable for various industrial and commercial electronic environments. The female contact gender configuration enables reliable connections with matching male headers in board-to-board systems.
This socket is ideal for industrial and manufacturing electronics assembly. It supports standard pitch layouts making it compatible with common PCB designs. Its durable materials offer extended operational life even under demanding conditions.
Designed for solder termination, it ensures stable mechanical and electrical connections. Applications include electronic device manufacturing, automation systems, and communication equipment. Originating from Switzerland, this product combines Swiss engineering precision and reliability. Explore more PCB Socket offerings and related electronic components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a maximum current of 12A and a voltage rating of 150V.
The pitch size of this socket is 2.54 mm, which is standard for PCB layouts.
The housing is made from black glass filled polyester, and the contacts are made of beryllium copper alloy plated with gold flash.
It is designed for operating temperatures from -55°C to 125°C, making it suitable for various environments.
This model uses solder termination for stable mechanical and electrical connections.
This socket features 6 contacts arranged in 2 rows.
The socket has a straight orientation, which facilitates efficient soldering on PCB surfaces.
It utilizes a board-to-board connector system with female contact gender.
Yes, it is ideal for industrial and manufacturing electronics assembly, as well as automation systems and communication equipment.
The Preci-Dip 803 Series socket originates from Switzerland, known for its engineering precision.
This socket is designed for surface mount, allowing easy PCB assembly.
It is suitable for applications in electronic device manufacturing, automation systems, and communication equipment.
