HARTING D-Sub 15 Way Right Angle 2.74 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert 09662526616

Free Delivery in India | Lowest Global Shipping Charges

HARTING D-Sub 15 Way Right Angle 2.74 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert 09662526616

Name: HARTING D-Sub 15 Way Right Angle 2.74 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Threaded Insert 09662526616
Brand: HARTING
SKU: 126831
Price: 8.77 USD
Availability: InStock



Category D-Sub Connector Brand HARTING Condition New

Specifications

Country of Origin	Switzerland
Brand	HARTING
Orientation	Right Angle
Current	7.5A
Mount Type	Through Hole
Housing Material	Steel
Contact Material	Copper Alloy
Series	D-Sub
Mounting Hardware	4 to 40 UNC Threaded Insert
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.74mm
Contact Plating	Gold
Number of Contacts	15
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub

Key Features

Features a right-angle orientation suitable for PCB mounting and space-saving applications.
Equipped with 15 contacts to support multiple signal connections.
Utilizes 4 to 40 UNC threaded inserts for secure mounting.
Constructed with steel housing and gold-plated copper alloy contacts for durability and conductivity.
Operates reliably within -55°C to 125°C temperature range.
Designed with solder termination for robust electrical connections.
Complies with IEC 60 807 standard for dependable performance.
Manufactured in Switzerland ensuring high product quality and durability.

Product Description

HARTING 09662526616 D-Sub Connector 15 Way Right Angle 2.74 mm Pitch Through Hole is engineered for industrial electronic applications requiring reliable and secure connections. This female connector features a 15-contact configuration designed for efficient signal transmission in power and data circuits.

Constructed with a robust steel housing, the connector provides excellent mechanical protection, while the copper alloy contacts with gold plating ensure high conductivity and resistance to corrosion. The right-angle orientation enables optimized PCB layout and space utilization.

Mounting is achieved through 4 to 40 UNC threaded inserts, offering sturdy mechanical fixation on circuit boards. The connector supports solder termination, facilitating durable electrical joints suited for industrial environments.

Operating across a broad temperature range from -55°C to 125°C, it performs reliably in harsh conditions common in industrial, manufacturing, and communications sectors.

The product adheres to IEC 60 807 standards, confirming its suitability for demanding electronic setups. Manufactured in Switzerland, it reflects excellent build quality and reliability.

Features a right-angle orientation suitable for PCB mounting and space-saving applications. Equipped with 15 contacts to support multiple signal connections. Utilizes 4 to 40 UNC threaded inserts for secure mounting. Constructed with steel housing and gold-plated copper alloy contacts for durability and conductivity.

Operates reliably within -55°C to 125°C temperature range. Designed with solder termination for robust electrical connections. Complies with IEC 60 807 standard for dependable performance. Manufactured in Switzerland ensuring high product quality and durability.

This connector is ideal for use in industrial machinery, telecommunications equipment, manufacturing lines, and electronic devices requiring secure and quality connections. Exploring more from HARTING and related D-Sub Connectors can enhance system design and reliability.
