JST PHD Series Right Angle Through Hole Shrouded PCB Header 10 Contacts 2 mm Pitch S10B-PHDSS(LF)(SN)(P)

JST S10B-PHDSS(LF)(SN)(P) is a right angle, shrouded PCB header from the JST PHD series, featuring 10 contacts with a fine 2 mm pitch. Designed as a wire-to-board connector, this through hole component ensures secure soldered connections with a double-row contact configuration.

The connector’s shrouded design protects contacts from incorrect mating and flux contamination, supporting high-density and low-profile PCB assemblies with a height of just 8.8 mm after mating. Constructed using copper alloy contacts plated with tin, it offers a current rating of 3 amperes and a voltage rating of 250 volts.

Operating temperature ranges from -55°C to 105°C make it suitable for demanding industrial environments. The solder termination and male contact gender ensure reliable electrical connectivity for circuit boards.

This PCB header finds applications in industries such as industrial automation, electronic manufacturing, HVAC control systems, telecommunication equipment, and laboratory instrumentation where robust and compact PCB connections are critical.

Right angle orientation supports tight PCB layouts. Shrouded contacts guard against mis-mating and contaminants. Copper alloy contacts with tin plating ensure conductivity and corrosion resistance. Rated for 3A current and 250V voltage for reliable electrical performance.

Through hole mounting with solder termination provides mechanical stability. Temperature durability between -55°C and 105°C for harsh environments. Low profile of 8.8 mm suits high-density PCB applications. Widely used in industrial, laboratory, and electronic manufacturing sectors.
