Texas Instruments I2C Translator Voltage Level Translator 2 Voltage Level, 8-Pin SSOP PCA9306DCTT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.3mm |
| Length | 4.25mm |
| Model | PCA9306DCTT |
| Mount Type | Surface |
| Output type | 3 State |
| Series | PCA9306 |
| Maximum Operating Temperature | 85°C |
| Package Type | SSOP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Number of Elements per Chip | 2 |
| Maximum Supply Voltage | 5V |
| Logic Family | I2C |
| Logic Function | Voltage Level Translator |
| Minimum Supply Voltage | 0mV |
| Maximum High Level Output Current | 128mA |
| Maximum Propagation Delay Time @ CL | 1.5ns |
| Direction Type | Bi-Directional |
| Translation | Voltage Level |
Key Features
- Supports bi-directional voltage level translation for I2C buses.
- Operates with a maximum supply voltage of 5V.
- Offers high maximum high-level output current of 128mA.
- Compact 8-pin SSOP surface-mount package ensures minimal board space.
- Wide operating temperature range from -40°C to 85°C for robust performance.
- Contains 2 elements per chip and features 3-state output type functionality.
- Low maximum propagation delay time of 1.5ns at CL for fast signaling.
- Suitable for I2C and SMBus serial communication protocols.
Product Description
Texas Instruments PCA9306DCTT is a high-performance I2C voltage level translator designed to facilitate communication between different voltage level devices on I2C or SMBus serial interfaces. This bi-directional translator allows seamless interfacing with two voltage supplies, supporting voltage translation between them while maintaining data integrity.
The device features an 8-pin SSOP surface-mount package with a compact height of 1.3mm and length of 4.25mm, making it suitable for space-constrained applications. It supports a maximum supply voltage of 5V and a maximum high-level output current of 128mA, ensuring reliable signal drive capability.
With a maximum propagation delay time of 1.5 nanoseconds at CL, the PCA9306DCTT supports high-speed data transfer across different voltage domains. It contains 2 elements per chip with 3-state output functionality essential for proper bus operation. The device operates reliably over a wide temperature range from -40°C to 85°C, accommodating industrial and commercial environments.
This voltage level translator is ideal for electronics, semiconductor, industrial machines, and lab equipment applications requiring electrical isolation or safe voltage interfacing between components operating at differing voltages. It meets standard semiconductor requirements though it is not automotive certified.
Supports bi-directional voltage level translation for I2C and SMBus protocols. Compact surface-mount SSOP package ensures minimal PCB footprint. Wide temperature range allows industrial usage. Low propagation delay supports fast communication.
High output current capability.
The PCA9306DCTT by Texas Instruments represents a reliable solution for enhancing interoperability and safety in mixed-voltage digital systems. It is widely used in semiconductor and electronics manufacturing, industrial instrumentation, and embedded designs.
Explore more high-quality Semiconductor components and electronic parts on EnvMart to optimize your manufacturing and design projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 5V.
It operates over a wide temperature range from -40°C to 85°C.
This unit contains 2 elements per chip.
The maximum high-level output current is 128mA.
It features a 3-state output type functionality.
The maximum propagation delay time is 1.5 nanoseconds at CL.
The PCA9306DCTT comes in an 8-pin SSOP surface-mount package.
It has a height of 1.3mm and a length of 4.25mm.
It supports I2C and SMBus serial communication protocols.
This model uses surface mounting.
Yes, it is suitable for industrial applications due to its wide operating temperature range and robust performance.
The country of origin for this model is India.
