Microchip MCP1726-3302E/SN 5-Channel Low Dropout Voltage Regulator 1A 3.3V SOIC 8-Pin
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.25mm |
| Length | 4.9mm |
| Model | MCP1726 |
| Width | 3.9mm |
| Mount Type | Surface |
| Output type | Fixed |
| Series | MCP1726 |
| Output Current | 1A |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Load Regulation | 0.5 % |
| Minimum Operating Temperature | -40°C |
| Polarity | Positive |
| Regulator Type | Low Dropout Voltage |
| Number of outputs | 5 |
| Maximum Input Voltage | 6V |
| Output Voltage | 3.3V |
| Quiescent Current | 140μA |
| Line Regulation | 0.05 %/V |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 2.3V |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
Key Features
- Features low dropout voltage ensuring efficient performance under varying load conditions.
- Operates with a supply input voltage range from 2.3V to 6V.
- Maintains output voltage accuracy with 0.05% line regulation and 0.5% load regulation.
- Includes five outputs delivering a regulated 3.3V fixed voltage at 1A current capacity.
- Compact SOIC 8-pin surface mount package measuring 4.9mm length by 3.9mm width and 1.25mm height.
- Operates reliably within temperature range of -40°C to 125°C, meeting automotive AEC-Q100 standards.
- Quiescent current consumption is low at 140μA, suitable for power-sensitive applications.
- Ensures positive polarity output and meets RoHS environmental standards.
Product Description
Microchip MCP1726-3302E/SN 5-Channel Low Dropout Voltage Regulator is a high-performance low dropout (LDO) linear regulator designed for delivering a stable 3.3V fixed output voltage at up to 1A output current. This device is supplied in a compact SOIC 8-pin package suitable for surface mounting on printed circuit boards. It operates with an input voltage range of 2.3V to 6V, making it versatile for various electronic applications requiring efficient power management.
The regulator offers excellent line regulation of 0.05%/V and load regulation of 0.5%, ensuring consistent voltage output even with load or input fluctuations. Quiescent current is minimal at just 140μA, making it ideal for battery-powered and power-sensitive devices. Its 5-channel output allows integration into complex circuits needing multiple regulated voltage lines simultaneously.
Measuring only 4.9mm in length, 3.9mm in width, and 1.25mm in height, the MCP1726 fits well in space-constrained assemblies. It supports operation in extended temperature ranges from -40°C to 125°C and conforms to automotive AEC-Q100 standards, attesting to its suitability for demanding industrial and automotive environments.
This regulator features positive output polarity and adheres to RoHS compliance, reflecting environmentally responsible manufacturing. It is extensively used in power management IC applications for electronics, automotive control units, and industrial equipment. The device’s reliable voltage regulation and thermal tolerance help improve system durability and efficiency.
Low dropout voltage for enhanced efficiency. Wide input voltage range from 2.3V to 6V. Stable and accurate 3.3V fixed voltage output. 5 output channels supporting multiple voltage lines. Compact SOIC 8-pin surface mount package.
Wide operating temperature range of -40°C to 125°C. Low quiescent current of 140μA for power-sensitive use. Compliance with RoHS and automotive AEC-Q100 standards. Positive polarity ensuring proper output polarity security.
This Microchip Voltage Regulator is recommended for industrial, automotive, electronic component, and power management use cases. It helps to design efficient, compact, and thermally robust circuits requiring stable voltage regulation. Explore the broader Power Management IC category on EnvMart for complementary components and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model delivers a regulated output voltage of 3.3V.
It has a maximum output current capacity of 1A.
It operates with an input voltage range from 2.3V to 6V.
This unit features five outputs, allowing for multiple regulated voltage lines.
It measures 4.9mm in length, 3.9mm in width, and 1.25mm in height.
The quiescent current consumption is low at 140μA, making it suitable for power-sensitive applications.
It offers a load regulation of 0.5%, ensuring consistent voltage output under varying load conditions.
It operates reliably within a temperature range of -40°C to 125°C.
It is supplied in a compact SOIC 8-pin surface mount package.
This model meets automotive AEC-Q100 standards, indicating its suitability for automotive applications.
Yes, it adheres to RoHS environmental standards, reflecting environmentally responsible manufacturing.
It features positive output polarity, ensuring proper output polarity security.
