JAE Copper Alloy Straight 7 Way Cable MIL Spec Circular Connector Male 500V AC 46A Shell Size 24 N/MS3106B24-10S
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 500V ac |
| Brand | JAE |
| Colour | Black |
| Orientation | Straight |
| Current | 46A |
| Model | N/MS3106B24-10S |
| Mount Type | Cable |
| Housing Material | Zinc |
| Contact Material | Copper Alloy |
| Series | N/MS |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Contact Plating | Silver |
| Number of Contacts | 7 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 24 |
| Military Standard | MIL-5015 |
| Connector Size | Standard |
| Shell Plating | Zinc |
Key Features
- The connector features a straight orientation ideal for cable applications.
- Constructed with a zinc housing and zinc-plated shell for durability and corrosion resistance.
- Contact material is copper alloy with silver plating to ensure excellent conductivity.
- Operating temperature range from -30°C to 85°C suits various environmental conditions.
- Termination is designed for solder connections ensuring secure and reliable joints.
- This MIL Spec Circular Connector meets rigorous military standards for industrial and electronic applications.
- Manufactured in Japan ensuring high-quality production standards.
Product Description
JAE N/MS3106B24-10S Copper Alloy Straight 7 Way Cable MIL Spec Circular Connector is a high-performance male connector with female contacts designed for cable mounting applications. Rated for 500V AC and 46A current, this connector features a shell size of 24 and complies with the MIL-5015 military standard, making it suitable for demanding industrial and electronic environments.
The connector features a straight design, facilitating secure cable connections. Its housing and shell are made of zinc with a protective zinc plating that enhances corrosion resistance and mechanical strength. The contacts are formed from copper alloy with silver plating to provide reliable electrical conductivity and resistance to wear.
Engineered to operate within temperatures ranging from -30°C to 85°C, this connector is robust for various industrial use cases. The solder termination type allows for solid and durable wire connections, ensuring stability in vibration-prone or harsh conditions.
This MIL Spec Circular Connector from JAE supports applications across military, industrial electronics, aerospace, and commercial sectors where certified rugged connectors are mandatory. Manufactured in Japan, it upholds quality and durability standards expected of high-reliability components.
The connector features a straight orientation ideal for cable applications. Constructed with a zinc housing and zinc-plated shell for durability and corrosion resistance. Contact material is copper alloy with silver plating to ensure excellent conductivity.
Operating temperature range from -30°C to 85°C suits various environmental conditions. Termination is designed for solder connections ensuring secure and reliable joints. This MIL Spec Circular Connector meets rigorous military standards for industrial and electronic applications.
Manufactured in Japan ensuring high-quality production standards. Explore more Mil Spec Circular Connectors and related electronic components in our comprehensive electronics category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for 500V AC.
It can handle a maximum current of 46A.
The operating temperature range is from -30°C to 85°C.
The housing and shell are made of zinc, while the contacts are copper alloy with silver plating.
This model features 7 contacts.
It uses solder termination for secure connections.
It complies with the MIL-5015 military standard.
The shell size of this connector is 24.
The operating temperature range and corrosion resistance suggest it can be used in various environmental conditions, but specific outdoor suitability is not stated.
It is manufactured in Japan, ensuring high-quality production standards.
It is suitable for military, industrial electronics, aerospace, and commercial applications where rugged connectors are required.
The connector features a straight orientation, making it ideal for cable applications.
