JAE Copper Alloy Straight 4 Way Cable MIL Spec Circular Connector Male Black, Female Contacts, Shell Size 18 N/MS3106B18-10S
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 500V |
| Brand | JAE |
| Colour | Black |
| Orientation | Straight |
| Current | 23A |
| Model | N/MS3106B18-10S |
| Mount Type | Cable |
| Housing Material | Zinc |
| Contact Material | Copper Alloy |
| Series | N/MS |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Contact Plating | Silver |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 18 |
| Military Standard | MIL-5015 |
| Connector Size | Standard |
| Shell Plating | Zinc |
Key Features
- The connector has a shell size of 18, suitable for robust industrial usage.
- Constructed with Zinc housing and Zinc shell plating ensuring durability and corrosion resistance.
- Designed for a current rating of 23A and voltage rating of 500V.
- Features female contact gender with silver plating for reliable electrical performance.
- The termination type is solder, ensuring secure connections.
- Operates efficiently between minimum -30°C and maximum 85°C temperature range.
- Complies with MIL-5015 military standard for quality assurance.
- Compact design with straight orientation for ease of cable assembly.
Product Description
JAE N/MS3106B18-10S is a Copper Alloy Straight 4 Way Cable MIL Spec Circular Connector designed for demanding electrical connectivity in industrial and military environments. This male connector features female contacts and a robust black Zinc housing with Zinc shell plating, making it resistant to wear and environmental stress.
Its standard shell size 18 accommodates four contacts, rated for 23 amperes and 500 volts, suitable for power and signal transmission in harsh conditions. The solder termination type provides reliable and secure electrical connections ideal for cable mount installations.
Operating performance ranges from a minimum temperature of -30°C to a maximum of 85°C, meeting rigorous MIL-5015 military standards for durability and performance. The connector's straight orientation facilitates straightforward cable assembly and integration into complex wiring systems.
Featuring silver-plated copper alloy contacts, the connector ensures optimal conductivity and corrosion resistance necessary for critical applications in industrial, military, aerospace, and transportation sectors. Manufactured in Japan, this product adheres to strict quality controls.
The connector has a shell size of 18, suitable for robust industrial usage. Constructed with Zinc housing and Zinc shell plating ensuring durability and corrosion resistance. Designed for a current rating of 23A and voltage rating of 500V.
Features female contact gender with silver plating for reliable electrical performance. The termination type is solder, ensuring secure connections. Operates efficiently between minimum -30°C and maximum 85°C temperature range.
Complies with MIL-5015 military standard for quality assurance. Compact design with straight orientation for ease of cable assembly. Product is manufactured in Japan ensuring high-quality standards.
This MIL Spec Circular Connector from JAE is an ideal solution for electronics components requiring rugged, high-performance cable connectors. It is widely used in industrial, military, aerospace, and manufacturing environments demanding reliable power and signal connectivity under adverse conditions.
Explore more JAE Mil Spec Circular Connectors and related electronics components at EnvMart to meet your technical and quality requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is designed for a current rating of 23A and a voltage rating of 500V, making it suitable for power and signal transmission.
It operates efficiently within a temperature range of -30°C to 85°C, allowing for use in various environments.
The connector features a Zinc housing and Zinc shell plating, with female contacts made of silver-plated copper alloy for enhanced conductivity and corrosion resistance.
This unit has four contacts, designed to accommodate various electrical connections.
It utilizes a solder termination type, ensuring secure and reliable electrical connections for cable mount installations.
The shell size of this connector is 18, which is suitable for robust industrial usage.
Yes, it complies with the MIL-5015 military standard, ensuring high-quality performance and durability.
The connector features a straight orientation, which facilitates straightforward cable assembly and integration into wiring systems.
This product is manufactured in Japan, adhering to strict quality controls.
The connector is black, providing a standard appearance suitable for various applications.
It is widely used in industrial, military, aerospace, and transportation sectors, requiring reliable power and signal connectivity in harsh conditions.
This model features a male connector gender with female contacts, designed for specific connectivity needs.
