Eaton xEffect Miniature Circuit Breaker 1-Pole 20A Type S 230V AC 10kA Breaking Capacity 278613 FAZ-S20/1

Eaton 278613 FAZ-S20/1 miniature circuit breaker is a high-quality protection device designed for industrial and commercial electrical distribution systems. This 1-pole breaker is rated at 20A with a Type S tripping characteristic, suitable for fast short-circuit interruption and overload protection at 230V AC voltage. It supports a breaking capacity of 10 kA, ensuring safe disruption of fault currents to protect electrical infrastructure.

The xEffect series by Eaton features current limiting technology that greatly reduces the let-through energy during short circuits, minimizing damage to wiring and connected equipment. Its thermal magnetic trip mechanism makes it responsive to both overload and instantaneous fault conditions.

The breaker is mounted via a DIN rail system, facilitating quick and secure installation. The device’s slim profile with a module width of 17.5 mm conserves panel space, allowing efficient use of electrical board real estate. Twin-purpose terminals provide flexibility for power feed orientation from either the line or load side.

Safety is enhanced with a finger-proof design and a trip-free mechanism preventing manual override of the trip function. This includes a toggle switch reset actuator for intuitive user operation. The product meets stringent IEC/EN 60947-2 standards, making it suitable for integration in industrial and commercial electrical systems.

Applications include control circuits, machinery protection, building electrical distribution boards, and HVAC systems. The compact size and robust design ensure reliable performance in industrial, manufacturing, and commercial electrical installations.

Thermal magnetic overcurrent protection provides reliable circuit safety. Easy installation on a DIN rail system with a compact 17.5 mm width. Complies with international IEC and EN standards for industrial use. Twin-purpose terminal allows versatile wiring configurations.

Instantaneous break time ensures rapid fault interruption. Finger-proof, trip-free mechanism enhances operational safety. Suitable for electrical distribution boards and control circuits industrially. Compact depth of 74 mm supports flexible panel layouts.

Type S tripping curve tailored for specific circuit protection needs.

Choose this Eaton Miniature Circuit Breaker for dependable, standard-compliant protection in industrial or commercial electrical systems. Explore our extensive range of Eaton products and other circuit protection solutions at EnvMart for your engineering and electrical needs.
