Eaton xEffect Miniature Circuit Breaker 1-Pole 3A Type S 230V AC 10 kA Breaking Capacity 278608 FAZ-S3/1

Eaton 278608 FAZ-S3/1 miniature circuit breaker from the xEffect range is a high-quality 1-pole device offering a current rating of 3A, Type S tripping characteristics, and a rated voltage of 230V AC. This breaker provides a breaking capacity of 10kA, ensuring fast and reliable interruption of short circuits and overload conditions.

The FAZ series features a thermal-magnetic tripping mechanism combining both thermal and electromagnetic protection, which effectively limits let-through currents and protects electrical installations from damage. This miniature circuit breaker is specifically designed for installation on DIN rails with a slim 17.5 mm width per pole, enabling efficient use of panel space.

Equipped with twin-purpose terminals, the breaker allows easy and secure wiring. Its finger-proof construction and trip-free mechanism enhance operational safety by preventing the breaker from being held in the ON position during fault conditions.

The device meets stringent IEC/EN 60947-2 standards for industrial low voltage circuit breakers and carries an IP20 rating, providing protection from accidental contact with live parts and ingress of solid foreign objects over 12.5 mm.

This Miniature Circuit Breaker is ideal for use in control circuits and electrical distribution boards in industrial, manufacturing, commercial, and building automation applications. The breaker enables clear indication of switch position through a front toggle actuator, simplifying system status checks and maintenance.

The compact design with a depth of 74mm and a small modular width supports space-saving panel layouts. Eaton’s xEffect range offers reliable protection and efficient electrical distribution solutions, including interlocks, busbars, and snap-on accessories compatible with the FAZ series breakers.

Thermal-magnetic overcurrent protection for effective fault clearance. DIN rail mountable with compact 17.5mm module width for 1-pole units. Twin-purpose terminal design for flexible wiring options. Instantaneous break time for prompt fault response.

Finger-proof and trip-free to enhance safety during operation. Complies with IEC/EN 60947-2 low voltage circuit breaker standards. IP20 rating for protection against accidental contact and solid particles. Application suited for electrical distribution and control circuits.

Clear contact position visible on toggle switch for easy monitoring. Depth of 74 mm supports compact electrical panel installation. Explore our extensive range of electrical protection devices and circuit breakers at EnvMart for industrial and commercial electrical applications.
