Eaton Industrial Motor Control Contactor 3-Pole 9 A 4 kW Coil Voltage 110V AC Model 276687 DILM9-10(110V50HZ,120V60HZ)

Eaton 276687 DILM9-10(110V50HZ,120V60HZ) is a high-quality industrial contactor designed for precise motor control in various commercial and industrial applications. It features a 3-pole configuration with a coil voltage rated at 110V AC, achieving efficient switching performance for motors and resistive loads up to 4 kW power rating and 9 A contact current at 400V AC.

The contactor boasts screw clamp terminals enabling easy and secure electrical connections with standard or Pozidriv screwdrivers, eliminating the need for specialized tools. Its compact dimensions of 68 mm length, 45 mm width, and 117 mm depth make it ideal for installations where space constraints exist.

Engineered for durability, this Eaton contactor endures up to 10 million mechanical operations, ensuring reliable long-term service. It operates safely within a temperature range from minus 25°C to 40°C, suitable for demanding industrial environments. The terminals are finger-proof to enhance safety during installation and maintenance.

The product complies with international standards including CSA, IEC/EN 60947, VDE 0660, and UL, ensuring compliance and safety. It includes 3 normally open poles and one auxiliary contact configured as 1 NO, widening its application versatility.

Weighing only 240 grams, this lightweight device reduces installation effort and enhances handling convenience. Commonly used in HVAC systems, manufacturing lines, and material handling equipment, it offers robust performance under electrical surges up to 8 kV AC, protecting against disturbances and faults.

The 276687 DILM9-10(110V50HZ,120V60HZ) is part of Eaton’s DILM series contactors, known for quality and reliability in motor control tasks across industrial automation systems. The Contactor supports a contact current of 9 A and contact voltage of 400V AC.

Designed for efficient motor control and resistive load handling with reversing capability. Includes screw clamp terminals that provide easy and safe wiring. Compact and lightweight design facilitates installation in constrained spaces.

Mechanical lifespan up to 10 million operations for extended durability. Compliant with major international safety standards including CSA, IEC/EN 60947, VDE, and UL. Operates reliably within a temperature range of -25°C to 40°C.

Features 3 NO poles and 1 NO auxiliary contact for versatile operation. Terminals positioned out of reach to enhance operator safety. Withstands voltage surges up to 8 kV AC, protecting connected equipment. Explore the comprehensive range of Eaton industrial electrical components in the EnvMart catalogue for reliable and efficient automation solutions.
