Schneider Electric TeSys K LP2K0910BD Contactor 24V DC Coil, 3-Pole, 9 A, 4 kW, 3NO, 690V AC
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load, Reversing |
| Length | 58mm |
| Model | LP2K0910BD |
| Depth | 57mm |
| Width | 90mm |
| Mount Type | DIN Rail |
| Series | TeSys K |
| Power Rating | 4kW |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 3 |
| Standards/Approvals | IEC, UL, RoHS, CSA, EAC, CCC |
| Contact Voltage | 690V ac |
| Coil Voltage | 24V dc |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 2 NO |
| Operational Current Ie | 9A |
| Control Circuit Voltage Uc | 24V dc |
| Contactor Application | Motor Control, Resistive Load |
| Pole and Throw Configuration | 3 |
Key Features
- Optimized for motor and resistive load control with a 3-pole configuration.
- Features a 24V DC coil for efficient low-voltage switching operations.
- Offers 9A contact current and 4 kW power rating for compact power solutions.
- Supports up to 690V AC contact voltage for demanding environments.
- Equipped with 3 NO main contacts and 2 NO auxiliary contacts for versatile control.
- DIN rail mount design simplifies installation and panel integration.
- Wide operating temperature range from -25°C to 50°C enhances application flexibility.
- Screw clamp terminals allow compatibility with solid and flexible cables.
Product Description
Schneider Electric LP2K0910BD is a premium TeSys K contactor designed for industrial motor control applications, featuring a 24V DC coil and robust 3-pole architecture. With a rated operating voltage of up to 690V AC, this contactor is perfectly suited for controlling resistive loads, reversible circuits, and machinery requiring reliable switching and protection.
The LP2K0910BD offers compact dimensions (58mm x 90mm x 57mm), making it ideal for tight panels and installations. Its 9A contact current and 4 kW power rating provide substantial operation capability for a range of industrial setups, including manufacturing, automation, and HVAC equipment.
The normal state configuration includes three normally open (3 NO) main contacts, while two auxiliary contacts are provided, both in a normally open (2 NO) arrangement to facilitate signalling and additional circuit control requirements. The contactor provides screw clamp terminals for both solid and flexible cables, ensuring ease and security of wiring during installation.
The device is designed for DIN rail mounting, streamlining integration within standard industrial panels and cabinets. Operational reliability is underscored by mechanical durability rated at approximately 5 million cycles, ensuring long lifespan even in demanding environments. Its operating temperature range from -25°C to 50°C accommodates diverse field conditions.
Compliant with international standards including IEC, UL, RoHS, CSA, EAC, and CCC, the TeSys K LP2K0910BD prioritizes safety, efficiency, and global usability. The product is manufactured in France, reflecting strict quality controls and advanced engineering.
Optimized for industrial, manufacturing, automation, and HVAC motor control. Ideal for environments requiring compact, durable power switching solutions. Employed in machinery, conveyor systems, and equipment with resistive or inductive loads.
Supports reversing functions for complex circuit operations. Easy integration and maintenance with screw terminals and DIN rail mount. Discover a comprehensive range of Contactors and motor-control solutions at EnvMart by Schneider Electric for diverse industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LP2K0910BD contactor has a power rating of 4 kW.
This model supports a maximum contact voltage of 690V AC.
The coil voltage for this contactor is 24V DC.
The LP2K0910BD contactor features a 3-pole configuration.
It has a contact current rating of 9A.
The dimensions of the LP2K0910BD are 58mm in length, 90mm in width, and 57mm in depth.
This model is equipped with screw clamp terminals for both solid and flexible cables.
The operating temperature range for this contactor is from -25°C to 50°C.
It is designed for DIN rail mounting, which simplifies installation and panel integration.
The LP2K0910BD has 2 normally open (2 NO) auxiliary contacts.
This contactor complies with international standards including IEC, UL, RoHS, CSA, EAC, and CCC.
It is optimized for motor control, resistive loads, and reversible circuits in industrial applications.
