Eaton xPole Miniature Circuit Breaker, 3-Pole, 13A, Type C, 400V AC, 48V DC, 10 kA Breaking Capacity 236424 PXL-C13/3

Eaton 236424 PXL-C13/3 Miniature Circuit Breaker is a high-quality 3-pole protective device rated for 13 amperes, featuring Type C tripping characteristics suitable for both AC and DC voltage systems. This versatile circuit breaker supports a rated AC voltage of 400V and a DC voltage up to 48V, crafted to deliver rapid and reliable circuit protection with a breaking capacity of 10 kA.

Designed for professional use in industrial, commercial, and residential electrical systems, it incorporates an electromagnetic tripping mechanism that ensures instantaneous interruption of fault currents, minimizing equipment damage and enhancing safety. The device includes a toggle switch reset actuator, enabling manual operation with ease and safety.

Constructed following strict EN 60898 and IEC standards, the PXL series breaker benefits from an IP20 rating, providing protection against accidental contact with live parts and ensuring finger-proof and back-of-hand-proof safety. The unit features compact dimensions of 80 mm width, 52.5 mm height, and 60 mm depth, making it ideal for tight installations.

This miniature circuit breaker mounts efficiently on standard DIN rails and comes with double terminal connections allowing secure wiring on both top and bottom ends. Its design allows flexible rail arrangements with quick-fit locking positions, ensuring rapid installation and maintenance. Compatibility with bus bars further extends its integration capability in electrical panels.

With its high selectivity and low passband energy features, the Eaton xPole PXL Miniature Circuit Breaker is engineered to act as an effective pre-fuse, enhancing the overall system protection and reliability across various electrical distribution applications.

Supports rated voltages of 400V AC and 48V DC ensuring versatile use in electrical setups. Features a breaking capacity of 10 kA, providing reliable protection against overcurrents. Equipped with a toggle switch reset actuator for easy manual operation.

Designed with an IP20 rating for finger and back-of-hand protection. Mounts easily on DIN rails with a compact dimension of 80mm width, 52.5mm height, and 60mm depth. Utilizes electromagnetic tripping mechanism delivering instantaneous break time for safety.

Manufactured according to EN 60898 and IEC standards for compliance and quality assurance. Constructed as part of the xPole PXL series, optimized for high selectivity and low passband energy applications. Compatible with bus bars and supports double terminal connections on both top and bottom.

Facilitates flexible rail arrangement both at the top and bottom with quick-fit locking positions for secure installation.

This product is ideal for industrial, commercial, residential, automation, and electrical infrastructure applications requiring efficient circuit protection. Eaton's commitment to quality and conformity ensures dependable performance and safety compliance for electrical distribution systems.
