Eaton xPole Miniature Circuit Breaker 3-Pole 20A Type C 400V AC 48V DC 10kA Breaking Capacity 236427 PXL-C20/3

Eaton 236427 PXL-C20/3 Miniature Circuit Breaker is a 3-pole device designed for electrical protection in industrial, commercial, and residential applications. It provides reliable circuit isolation and fault interruption with a rated current of 20A and Type C tripping characteristics suitable for circuits with moderate inrush currents.

The breaker operates efficiently at voltages up to 400V AC and 48V DC, enabling use in diverse electrical environments. Its high breaking capacity of 10kA ensures robust protection against short circuits and overloads.

Featuring a compact form factor, the breaker has a width of 80mm, height of 52.5mm, and depth of 60mm, optimized for DIN rail mounting. The quick-fit action with three locking positions simplifies installation in electrical panels and switchboards.

Safety is enhanced with an IP20 rating, providing finger-proof and back-of-hand protection. The toggle switch actuator allows easy manual resetting, while the electromagnetic tripping mechanism ensures precise fault detection and response.

Complying with international standards IEC 60898 and EN 60898, this circuit breaker meets stringent quality and performance benchmarks. Originating from Austria, the Eaton PXL series combines durability and high selectivity, making it a preferred choice for electrical distribution systems in manufacturing, HVAC, industrial plants, and commercial buildings.

This 3-pole miniature circuit breaker is suitable for protection against overload and short-circuits. The Type C tripping curve suits applications with moderate inrush, such as motors and lighting circuits. Its DIN rail mount facilitates fast and versatile installation in electrical enclosures.

The breaker offers a breaking capacity of 10kA, ensuring reliable interruption under fault conditions. Compact size and IP20 protection rating enhance safety and integration flexibility. Eaton's xPole PXL series is known for high selectivity and compatibility with bus bars.

The device supports both AC and DC voltages, expanding its applicability in hybrid systems. It includes double terminal connections with lift/jaw features for secure wiring. Manufactured in Austria under strict quality standards for industrial use.
