ITT Cannon Circular Connector 48 Contacts Panel Mount Socket Male IP67 Trident Neptune Series TN7S24-0048P1L / 192900-0437

Free Delivery in India | Lowest Global Shipping Charges

ITT Cannon Circular Connector 48 Contacts Panel Mount Socket Male IP67 Trident Neptune Series TN7S24-0048P1L / 192900-0437

Name: ITT Cannon Circular Connector 48 Contacts Panel Mount Socket Male IP67 Trident Neptune Series TN7S24-0048P1L / 192900-0437
Brand: ITT CANNON
SKU: 117210
Price: 41.41 USD
Availability: InStock



Category Industrial Circular Connectors Brand ITT CANNON Condition New

Specifications

Country of Origin	Hungary
Voltage	250V
Brand	ITT Cannon
Orientation	Straight
Current	30A
Model	TN7S24-0048P1L / 192900-0437
IP Rating	IP67
Mount Type	Panel Mount
Housing Material	Polymer
Contact Material	Copper
Series	Trident Neptune
Termination Type	Crimp
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Pole Format	48
Contact Plating	Nickel
Number of Contacts	48
Contact Gender	Male
Shell Size	24 mm
Mating Type	Bayonet
Connector Size	Standard
Plug/Socket	Socket

Key Features

Panel mount design with jam nut fixing for secure attachment.
Provides 48 contacts with a current rating of 30A for reliable power and signal transmission.
Standard connector size with 24 mm shell size and straight orientation.
Features IP67 rating ensuring protection against dust and water ingress.
Constructed with a polymer housing and copper nickel-plated contacts for durability.
Suitable for operating temperature range from -55°C to 105°C.
Termination by crimp technique for flexible wiring.
Employs a bayonet mating type for quick and secure connections.

Product Description

ITT Cannon TN7S24-0048P1L / 192900-0437 Circular Connector, part of the Trident Neptune Series, is a high-performance industrial circular connector designed for panel mounting. This connector features 48 contacts, providing a robust interface for both power and signal transmission. With a current rating of 30A and a voltage rating of 250V, it ensures reliable electrical connectivity in demanding environments.

The connector utilizes a standard size shell of 24 mm with a straight orientation and a bayonet mating system, facilitating easy and secure coupling. It features a socket construction with male contact gender, suitable for various industrial assembly needs. The polymer housing and nickel-plated copper contacts enhance its durability and corrosion resistance.

Rated to IP67, the connector offers excellent protection against dust and water, making it ideal for harsh indoor and outdoor applications. Operating temperature spans from -55°C to 105°C, ensuring stable performance across diverse conditions. The termination type is crimp, allowing flexible and secure cable connections.

Designed for automotive, marine, and process control industries, this connector supports demanding operational environments. The panel mount design features jam nut fixing, allowing mounting from the rear and enabling both panel and in-line connections. It includes 'O' ring seals and rubber cable seals to maintain the IP67 ingress protection level.

Panel mount with jam nut fixing for rear mounting on 'D' holes. 48 contacts accommodating power and signal circuits with 30A current rating. Bayonet coupling system ensures secure and quick mating. Polymer housing offers lightweight durability and enhanced insulation.

Nickel-plated copper contacts promote excellent conductivity and corrosion resistance. IP67 protection for dust-tight and water immersion resistant performance. Suitable for extreme temperatures from -55°C up to 105°C. Crimp termination facilitates reliable cable attachment.

This ITT Cannon connector is widely used across industrial power connectors, automotive assembly, marine electrical systems, and process control instrumentation. Its design ensures a secure and dependable connection in critical environments requiring IP67 rated protection and robust mechanical stability.

Explore the comprehensive range of Industrial Circular Connectors and accessories available at EnvMart for a complete and compatible installation solution.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The connector has a current rating of 30A and a voltage rating of 250V, ensuring reliable electrical connectivity.

This model features an IP67 rating, providing protection against dust and water ingress, making it suitable for harsh environments.

The housing is made from polymer, while the contacts are constructed from copper and nickel-plated for enhanced conductivity and corrosion resistance.

It operates effectively within a temperature range of -55°C to 105°C, suitable for diverse environmental conditions.

This connector features 48 contacts, accommodating both power and signal circuits.

It employs a crimp termination type, allowing for flexible and secure cable connections.

The connector has a standard shell size of 24 mm, designed for panel mounting.

This model utilizes a bayonet mating type, which ensures quick and secure connections.

It features a panel mount design with jam nut fixing, allowing for rear mounting on 'D' holes.

This connector is suitable for automotive, marine, and process control industries, particularly in demanding operational environments.

The connector has a male contact gender, designed for use in various industrial assembly applications.

Nickel plating on the contacts promotes excellent conductivity and provides corrosion resistance, enhancing the connector's performance in challenging conditions.
