| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C2V7YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 2.7V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 600Ω |
| Typical Voltage Temperature Coefficient | -3.5mV/K |
Nexperia BZX8850S-C2V7YL is a single-element 2.7 V Zener diode designed for voltage regulation in an ultra-compact DFN1006BD-2 surface mount package. With a maximum power dissipation of 365 mW, this diode supports low-current regulation functions with a test current of 50 μA, ideally suited to portable and battery-powered devices.
The device offers robust performance over an operating temperature range of -55°C to 150°C, making it reliable across various industrial and automotive applications. Its voltage tolerance of ±5% ensures stable operation in sensitive circuits requiring precise voltage control.
Featuring an ultra-small 2-pin package with side-wettable flanks, the BZX8850S-C2V7YL supports compact PCB designs and automated assembly processes. It adheres to the AEC-Q101 automotive standard, suitable for use within automotive electronic systems.
Typical applications include general voltage regulation, low bias portable electronics, automotive systems, and other low-power, low-voltage circuit protection implementations. This diode features a low test current of 50 μA, ideal for low bias and battery-powered applications.
It is housed in an ultra-small 2-pin DFN1006BD-2 plastic surface mount package with side-wettable flanks. The device operates within a temperature range of -55°C to 150°C, ensuring reliability in various environments. The Zener voltage tolerance is ±5%, supporting precise voltage regulation functions.
Its maximum power dissipation is 365 mW, suitable for low-current voltage regulation tasks. Typically used in automotive systems, adhering to AEC-Q101 automotive standards. The diode exhibits a maximum Zener impedance of 600 Ω and maximum reverse leakage current of 1 μA.
The working voltage range spans nominally from 1.8 V to 75 V for versatile design integration. Explore more Zener Diodes and semiconductor components at EnvMart for diverse industrial, automotive, and electronic manufacturing needs.
