TDK 22 nF 50V DC Multilayer Ceramic Capacitor, ±10 % Tolerance, Surface Mount 0603 Case C1608X7R1H223K080AA

Free Delivery in India | Lowest Global Shipping Charges

TDK 22 nF 50V DC Multilayer Ceramic Capacitor, ±10 % Tolerance, Surface Mount 0603 Case C1608X7R1H223K080AA



Category Multilayer Ceramic Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Voltage	50V dc
Brand	TDK
Height	0.8mm
Length	1.6mm
Model	C1608X7R1H223K080AA
Packaging	Tape & Reel
Width	0.8mm
Mount Type	Surface
Construction	Stacked
Termination Type	Surface Mount
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	22nF
Minimum Operating Temperature	-55°C
Standards/Approvals	REACH, RoHS
Package/Case	0603
Dielectric	X7R

Key Features

Constructed with stacked multilayer dielectrics and inner electrodes for high reliability.
Compact 1.6 mm length, 0.8 mm width, and 0.8 mm height dimensions.
Dielectric type X7R offers stable performance from -55°C to 125°C operating temperature range.
Features low ESR and ESL for outstanding frequency characteristics.
Non-polarized, suitable for general electronics including power supply, AV, telecom, and computing applications.
Compliant with REACH and RoHS environmental standards.
Packaged in tape & reel for efficient automated PCB assembly.
Surface mount termination ensures compatibility with modern SMT manufacturing processes.

Product Description

TDK C1608X7R1H223K080AA is a high-quality 22 nF multilayer ceramic capacitor designed for surface mount technology applications. It features a 50V DC voltage rating and a ±10 % capacitance tolerance, making it suitable for use in a variety of electronic devices and circuits.

The capacitor’s construction involves alternately stacked multilayer dielectrics and inner electrodes, resulting in a monolithic component that delivers superior mechanical strength and reliability. Its X7R dielectric material ensures stable capacitance across a wide temperature range from -55°C to 125°C, suitable for industrial, telecommunications, automotive, and consumer electronics.

With low equivalent series resistance (ESR) and low equivalent series inductance (ESL), this component supports excellent frequency characteristics and minimizes self-heating and ripple effects under operational loads.

Its compact 0603 package measures 1.6 mm by 0.8 mm by 0.8 mm, fitting space-constrained surface-mount PCBs. The component is non-polarized, simplifying installation and allowing use in AC and DC circuits.

Stacked multilayer construction provides high reliability and durability. Wide operating temperature ensures performance consistency in harsh environments. Low ESR and ESL optimize frequency response and minimize losses.

Surface mount package aids automated manufacturing compatibility. REACH and RoHS compliance ensure environmental safety and regulatory adherence. Tape & reel packaging supports high-volume manufacturing processes. This capacitor is ideal for use in industrial controls, communication equipment, power supplies, consumer electronics, and other precision electronic applications.
