Phoenix Contact PC 6/-GL-THR Series Pluggable Terminal Block 5-Contact 7.62 mm Pitch 1 Row, 1190540

Phoenix Contact 1190540 is a high-quality PC 6/-GL-THR series pluggable terminal block offering 5 contacts with a pitch of 7.62 mm and a single-row layout. It is specifically engineered for printed circuit board (PCB) applications, featuring a self-locking flange and wave soldering mounting configuration to ensure robust mechanical and electrical performance.

The terminal block's housing is crafted from a black liquid crystal polymer, which provides high durability, heat resistance, and excellent mechanical stability in demanding industrial environments. The male connector with a straight orientation facilitates straightforward PCB integration and connection reliability.

Rated for a nominal current of 41 A and a voltage of 630 V, this component supports power and signal transmission in industrial automation, electronic equipment, and power distribution systems. The copper alloy contact material ensures excellent electrical conductivity, while the dimensions (28.2 mm length, 46.12 mm width, and 15.6 mm depth) allow for compact and efficient PCB layouts.

The product conforms to a comprehensive set of international standards including IEC 61760-1:2006-04, IEC 61984, IEC 60068-2-58:2015-03, IPC/JEDEC J-STD-020E:2014-12, ISO 6988, and COMBICON ensuring safety, reliability, and quality compliance for industrial and electronic applications.

This terminal block is ideal for integration into SMT soldering processes and provides increased touch protection in the pin connector pattern for maximum safety even when not plugged in. It supports easy PCB replacement thanks to modular plug-in design, making maintenance and system upgrades straightforward and cost-effective.

This terminal block supports a nominal current of 41 A for robust electrical performance. Constructed with a black liquid crystal polymer housing for durability and heat resistance. The connector features a male, straight orientation ensuring easy integration.

Designed for a voltage rating of 630 V, suitable for a variety of industrial applications. Compliant with multiple international standards including IEC 61760-1 and IEC 61984 for safety and reliability. Dimensions include length of 28.2 mm, width of 46.12 mm, and depth of 15.6 mm for compact PCB designs.

Material contacts are made from copper alloy ensuring good electrical conductivity.

This product fits within industrial, electronics manufacturing, automation, power distribution, and laboratory equipment applications. It is a reliable choice for engineers and technicians requiring a compact, high-current rated, and safety-certified pluggable terminal block solution.
