Infineon Smart High-Side Power Switch Arduino Shield with Protection and Diagnostic Features BTS7004-1EPP

Infineon BTS7004-1EPP is a smart high-side power switch integrated into an Arduino shield featuring embedded protection and comprehensive diagnostic capabilities. Designed as part of the PROFET™+2 12V family, it supports automotive-grade applications with compliance to stringent quality and operational standards. This device facilitates control and protection of 12V power outputs and is optimized for driving 15 A resistive, inductive, and capacitive loads, effectively replacing electromechanical relays, fuses, and discrete circuits.

The shield demonstrates practical relay and fuse replacement by allowing activation and deactivation of loads such as bulbs, heating elements, and motor drives. It provides accurate load current measurement and detects no-load scenarios, enhancing system reliability and diagnostics. The product is RoHS compliant, ensuring environmental safety, and meets automotive qualification with product validation to AEC-Q100 Grade 1 standards.

Additional protective features include overcurrent protection through an intelligent latch mechanism and undervoltage shutdown, which safeguard the device and connected systems during fault conditions or unstable supply voltages. The robust design supports extended and high-temperature mission profiles, making it suitable for demanding automotive and industrial environments.

This Arduino shield is highly applicable in electronic development platforms, automotive power management, industrial automation, and educational STEM toolkits. It simplifies the implementation of high-side switching with integrated diagnostic functions, streamlining prototyping and testing efforts.

Part of the PROFET™+2 12V device family engineered for automotive applications. Provides overcurrent protection with intelligent latch to prevent damage. Includes undervoltage shutdown features for safe operation under supply faults.

Controls resistive, inductive, and capacitive loads up to 15 A. Demonstrates relay and fuse substitution via Arduino shield integration. Measures load current and detects no-load condition for diagnostics. Complies with the Restriction of Hazardous Substances (RoHS) directive.

Validates to AEC-Q100 Grade 1 for automotive reliability. Explore more Arduino Shields and electronic components within the EnvMart platform to support your embedded system development and industrial automation projects.
