| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 1.15mm |
| Length | 3.1mm |
| Model | BZX84B13VLYT116 |
| Mount Type | Surface |
| Series | BZX84B |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 250mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 100nA |
| Nominal Zener Voltage Vz | 13V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 30Ω |
| Typical Voltage Temperature Coefficient | 11mV/°C |
The ROHM BZX84B13VLYT116 is a high-quality Zener diode designed for voltage regulation in electronics applications. It features a nominal Zener voltage of 13 V and is built to handle a maximum power dissipation of 250 mW, making it suitable for low power stability and voltage clamping use cases. The device comes in a compact surface mount SOT-23 package with 3 pins, enabling easy integration into densely populated circuit boards.
This single-element Zener diode operates reliably up to a maximum temperature of 150°C and complies with RoHS environmental standards ensuring eco-friendly manufacturing. The diode is also qualified to the automotive standard AEC-Q101, indicating its suitability for automotive electronics and other demanding industrial applications.
The diode has a typical voltage temperature coefficient of 11 mV per degree Celsius, which allows predictable performance changes over temperature variation. Its low maximum reverse leakage current of 100 nA and maximum Zener impedance of 30 Ω contribute to efficient operation and stable voltage regulation.
Measuring just 3.1 mm in length and 1.15 mm in height, this device offers a space-saving solution for voltage regulation on compact PCBs. The test current is specified at 5 mA, ensuring consistent characterization and quality assurance during manufacturing.
Nominal Zener voltage of 13 V. Maximum power dissipation of 250 mW. Compact 3-pin SOT-23 surface mount package. Maximum operating temperature of 150°C for harsh environments. Compliance with RoHS and AEC-Q101 automotive standards.
Voltage temperature coefficient of 11 mV/°C for stability over temperature. Low maximum reverse leakage current of 100 nA. Test current of 5 mA ensuring consistency. Maximum Zener impedance of 30 ohms. Small physical size for PCB space optimization.
Typical industry applications include industrial electronics, automotive electronics, power supply regulation, and any circuit requiring precise voltage stabilization. This product is ideal for engineers and designers seeking robust Zener diode solutions in surface-mount format.
