Souriau Sunbank by Eaton Aluminium Straight 26 Way MIL Spec Circular Connector 7.5A 1500V Female Contacts 85107R1626S5044
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1500V |
| Brand | Souriau Sunbank by Eaton |
| Orientation | Straight |
| Current | 7.5A |
| Model | 85107R1626S5044 |
| IP Rating | IP68, IP67, IP65 |
| Housing Material | Thermoplastic |
| Contact Material | Aluminium |
| Series | 851 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Contact Gender | Female |
| Shell Size | 25.42 mm |
| Mating Type | Bayonet |
| Connector Size | Standard |
Key Features
- Constructed with thermoplastic housing and aluminium contacts for durability.
- Features gold plating on contacts to ensure reliable electrical connections.
- Equipped with a bayonet mating type for secure and quick coupling.
- Supports a wide operating temperature range from -55°C to 125°C.
- Provides IP68, IP67, and IP65 ingress protection ratings for environmental sealing.
- Designed to withstand salt spray and corrosive atmospheres for extended use.
- Shell size of 25.42 mm accommodates up to 26 contacts.
- Connector termination is crimp type for ease of installation.
Product Description
Souriau Sunbank by Eaton 85107R1626S5044 Aluminium Straight 26 Way MIL Spec Circular Connector offers a robust and reliable connection solution suitable for demanding industrial, aeronautical, and military applications. This connector features female contacts and a straight orientation with a durable thermoplastic housing and aluminium contact material with gold plating for enhanced conductivity and corrosion resistance.
Operating up to 7.5 amps and 1500 volts, it ensures stable electrical performance even under harsh conditions. The bayonet mating system allows quick and secure coupling, making installation and maintenance efficient. The connector's shell size is 25.42 mm and supports 26 contacts, offering ample connectivity in a compact form factor.
Designed to operate in extreme environmental conditions, it withstands temperatures from -55°C to +125°C and provides ingress protection ratings of IP68, IP67, and IP65 to guard against dust and water penetration. Its robust construction features stainless steel bayonet pins and backshell, providing resistance to salt spray and corrosive atmospheres while maintaining mechanical and electrical integrity.
The connector is rated for 500 mating/unmating cycles, ensuring durability and longevity in repeated use. It also holds a UL94 HB flammability rating, emphasizing safety. This product complies with RoHS directives, ensuring environmentally-friendly manufacturing and materials.
Manufactured in France, this MIL Spec Circular Connector is trusted in aerospace, defense, industrial, and commercial sectors for reliable and high-performance interconnections. Souriau Sunbank by Eaton's 851 series is engineered to meet rigorous standards required in challenging environments.
Durable thermoplastic housing and aluminium contacts with gold plating. Bayonet mating type for secure connections. IP68, IP67, and IP65 ratings for environmental protection. Wide temperature operation from -55°C to 125°C.
500 mating/unmating cycles for extended life. Salt spray resistant up to 500 hours. RoHS compliant. Shell size 25.42 mm and 26 contacts. Explore more Souriau Sunbank by Eaton Mil Spec Circular Connectors for advanced industrial and military applications at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a maximum voltage rating of 1500 volts.
It is rated for a maximum current of 7.5 amps.
The housing is made of thermoplastic, and the contacts are made of aluminium with gold plating for enhanced conductivity.
It operates within a wide temperature range from -55°C to +125°C.
This connector features a bayonet mating type for secure and quick coupling.
It supports up to 26 female contacts.
The connector has IP68, IP67, and IP65 ingress protection ratings, ensuring environmental sealing against dust and water.
The shell size is 25.42 mm.
It is rated for 500 mating/unmating cycles, ensuring durability in repeated use.
Yes, it complies with RoHS directives, ensuring environmentally-friendly manufacturing and materials.
This connector is manufactured in France.
The connector uses a crimp type for ease of installation.
