Amphenol Limited MIL Spec Circular Connector Copper Alloy Straight 4 Way Box Mount 850V 7.5A 62GB-12E08-04PN-760
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 850V |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 7.5A |
| Model | 62GB-12E08-04PN-760 |
| Temperature Operating Range | -55°C to 125°C |
| Mount Type | Box Mount |
| Contact Material | Copper Alloy |
| Series | 62 GB |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Connector Gender | Female |
| Shell Size | 8 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Wire gauges and current carrying capabilities | Upto 45A and size 24 to 8 AWG wires |
Key Features
- Manufactured with a copper alloy contact material plated with gold for excellent conductivity.
- Designed to meet MIL-DTL-26482 military standard with a box mount and bayonet mating type.
- Features a standard shell size 8 and a crimp termination type for reliable wiring.
- Operates in a temperature range of -55°C to 125°C with a liquid-tight neoprene insulator.
- Includes 4 male contacts with female connector gender configuration.
- Compatible with wire gauges from 24 to 8 AWG and supports up to 45A current capacity.
- Connector orientation is straight without strain relief features.
- Ideal for industrial, military, aerospace, and harsh environment applications.
Product Description
Amphenol Limited 62GB-12E08-04PN-760 MIL Spec Circular Connector is a high-quality electrical connector designed for demanding industrial and military applications. This copper alloy, straight 4 way box mount connector provides secure and reliable connections with a bayonet mating type and a standard shell size 8. Its gold-plated copper alloy contacts ensure excellent conductivity and resistance to corrosion.
The connector is designed to operate efficiently within a broad temperature range from -55°C to 125°C, making it suitable for extreme environmental conditions. It uses a crimp termination type compatible with wire gauges 24 to 8 AWG and supports currents up to 45 amps, offering high-performance electrical characteristics.
It complies with the MIL-DTL-26482 military standard ensuring reliability and durability required in aerospace, defense, and industrial sectors. The box mount feature allows easy panel installation while the resilient neoprene insulator integrated with rear wire sealing grommet offers liquid-tight assembly and protection against environmental factors.
Made with copper alloy contacts plated in gold for enhanced conductivity and corrosion resistance. Meets MIL-DTL-26482 military specifications for rugged industrial use. Four male contacts with female connector interface ensure compatibility and secure fit.
Rated voltage of 850V and current rating of 7.5A for dependable power transmission. Operates in temperatures from -55°C to 125°C suitable for harsh environments. Features crimp termination and straight orientation with standard shell size 8.
Supports wire sizes from 24 to 8 AWG and current capacity up to 45A. Ideal for industrial, aerospace, military, and high-reliability connection needs.
This connector provides an excellent solution for demanding applications requiring durability, reliability, and compliance with military standards. It is suitable for use in electronic components, power distribution, aerospace systems, instrumentation, control panels, and other harsh environment installations.
Explore more connectors compliant with MIL standards and other high-performance electronic components in the Electronics Components category on EnvMart.
Explore more products in our Mil Spec Circular Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a voltage rating of 850V, making it suitable for various electrical applications.
This model supports a current capacity of up to 45A, which is suitable for high-performance electrical connections.
It operates efficiently within a temperature range of -55°C to 125°C, allowing it to function in extreme environments.
The connector features 4 male contacts, designed for secure and reliable connections.
It utilizes a crimp termination type, which is compatible with wire gauges from 24 to 8 AWG.
This connector complies with the MIL-DTL-26482 military standard, ensuring reliability in demanding applications.
The connector has a standard shell size of 8, which is common for many military and industrial applications.
It features a bayonet mating type, which provides secure and reliable connections.
The contacts are made from copper alloy and are plated with gold for excellent conductivity and corrosion resistance.
The orientation of this model is straight, which is suitable for many installation scenarios.
The connector is manufactured in the United Kingdom, ensuring compliance with quality standards.
It is ideal for industrial, military, aerospace, and harsh environment applications, ensuring reliable performance in demanding conditions.
