Souriau Sunbank by Eaton 6 Way Cable Connector 600V 7.5A Shell Size 10 Bayonet Mount MIL-DTL-26482 85136RG106S50

The Souriau Sunbank by Eaton model 85136RG106S50 is a 6 Way Cable Connector designed to meet rigorous industrial and military standards including MIL-DTL-26482. Featuring male and female contacts, this connector has a shell size 10 and bayonet mating style, optimized for cable mount installations. Operating voltage is rated at 600 volts with a current capacity of 7.5 amps, making it suitable for demanding electrical connections.

The connector shell is plated with iridescent yellow cadmium, providing excellent resistance against corrosion, especially in saline or harsh atmospheric conditions. The female contacts are nickel plated to ensure high conductivity and durability.

Designed to function reliably across a wide temperature range from -55°C up to 125°C, the connector is rated IP65 for environmental protection against dust ingress and low-pressure water jets, helping maintain performance in challenging climates. The straight connector orientation simplifies installation and cabling layout in aerospace, military, and industrial equipment.

The product supports up to 500 mating/unmating cycles, emphasizing long service life and reduced maintenance needs. It holds a UL94 HB flammability rating ensuring safety under heat stress.

Manufactured in France under strict quality standards, the 851 series connectors are trusted in applications requiring high mechanical and electrical reliability, such as aeronautical systems, military hardware, and industrial automation.

Rated for 600 volts and 7.5 amps current capacity. Bayonet type mating mechanism with shell size 10. Durable corrosion-resistant iridescent yellow cadmium plating on the shell. Nickel plated female contacts for enhanced reliability.

Wide operating temperature range from -55°C to +125°C. Provides IP65 protection against dust and water exposure. Complies with MIL-DTL-26482 military standards. Designed for 500 mating/unmating cycles. Manufactured in France ensuring quality and performance.

These features make the 85136RG106S50 connector ideal for use in industrial, military, laboratory, aerospace, and other precise technical environments requiring robust and reliable electrical connectivity.
