Amphenol Limited MIL Spec Circular Connector 19 Contacts Copper Alloy Straight Box Mount 700V 7.5A 62GB-12E14-19SN-219
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 700V |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 7.5A |
| Model | 62GB-12E14-19SN-219 |
| Temperature Operating Range | -55°C to 125°C |
| Mount Type | Box Mount |
| Contact Material | Copper Alloy |
| Series | 62 GB |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 19 |
| Contact Gender | Male |
| Connector Gender | Female |
| Shell Size | 14 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Wire gauges and current carrying capabilities | Upto 45A and size 24 to 8 AWG wires |
Key Features
- This MIL-DTL-26482 certified connector supports a voltage rating of 700V and current rating of 7.5A.
- The connector is designed with a straight orientation and a box mount type for secure installation.
- It features a crimp termination type and bayonet mating for secure mechanical and electrical connection.
- The operating temperature range is from -55°C to 125°C, suitable for harsh industrial environments.
- Contact material uses copper alloy with gold plating for enhanced conductivity and corrosion resistance.
- The connector accommodates wire gauges from size 24 to 8 AWG, supporting currents up to 45A in application.
- The shell size is 14 with standard connector size, providing a compact yet durable footprint.
- Manufactured in the United Kingdom, this product ensures high quality and compliance with MIL spec standards.
Product Description
Amphenol Limited 62GB-12E14-19SN-219 MIL Spec Circular Connector is a high-performance industrial connector engineered for demanding applications in electronics, power, and communications sectors.
Featuring 19 male contacts and a female shell, this connector utilizes copper alloy contacts plated with gold to ensure excellent electrical conductivity and corrosion resistance. Its straight orientation and box mount configuration enable secure and reliable mounting in equipment assemblies.
Certified to MIL-DTL-26482 standards, the connector operates safely in temperature ranges from -55°C to 125°C, making it suitable for industrial, military, aerospace, and harsh environmental applications. The crimp termination type facilitates strong wire connections, supporting wire gauges from 24 to 8 AWG and current capacities up to 45A under specified conditions.
The connector's shell size 14 design with bayonet mating provides quick and secure mechanical coupling, minimizing mis-mating risks with its keyway orientation. This robust construction includes a resilient neoprene insulator with rear wire sealing grommet to guarantee a liquid-tight assembly, protecting internal contacts from environmental contamination.
This circular connector is ideal for industrial, military, aerospace, and communication system manufacturers requiring durable, high-reliability connectors that meet stringent MIL standards.
This MIL spec circular connector supports up to 700V voltage and 7.5A current ratings. Its operating temperature range covers -55°C to 125°C for extreme environment compatibility. Copper alloy contacts with gold plating ensure high conductivity and corrosion resistance.
Bayonet mating and box mount design secure robust mechanical and electrical connections. Compatible with wire sizes 24 to 8 AWG and currents up to 45A in application. Constructed for industrial and military use with liquid-tight sealing.
Manufactured in the United Kingdom to ensure quality and compliance. For more products like this, explore the Mil Spec Circular Connectors category at EnvMart for reliable industrial-grade electrical connectors from top brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector supports a voltage rating of 700V and a current rating of 7.5A.
It operates within a temperature range of -55°C to 125°C, suitable for harsh environments.
This model features a crimp termination type for secure wire connections.
The connector is equipped with 19 male contacts.
The shell size of this connector is 14, which is a standard size.
The contacts are made of copper alloy and are plated with gold to enhance conductivity and corrosion resistance.
It features a box mount type for secure installation.
This model utilizes bayonet mating for secure mechanical and electrical connections.
It accommodates wire gauges from size 24 to 8 AWG.
In application, it supports currents up to 45A.
Yes, it is certified to MIL-DTL-26482 standards.
This product is manufactured in the United Kingdom.
