Hirose DF65 Series Straight Surface PCB Header, 3 Contacts, 1.7 mm Pitch, 1 Row, Shrouded DF65
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 4A |
| Model | DF65 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Brass |
| Series | DF65 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.7mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 1mm |
Key Features
- Features a 1-row, shrouded configuration for secure connections.
- Manufactured with liquid crystal polymer housing for durability.
- Brass contacts plated with tin ensure excellent conductivity.
- Supports a maximum current of 4A and voltage rating of 50V.
- Operates reliably between -40°C and 105°C temperature range.
- Surface mount type with solder termination for easy PCB integration.
- 1 mm tail pin length enhances secure soldering and contact.
- Designed and made in Japan for high quality and performance.
Product Description
Hirose DF65 Series Straight Surface PCB Header DF65 is a 3-contact, low-profile PCB connector with a 1.7 mm pitch and a single row shrouded design. Constructed with a liquid crystal polymer housing and brass contacts plated with tin, it offers durability and reliable electrical connectivity for electronic assemblies.
The surface mount solder termination ensures easy installation on printed circuit boards while maintaining strong mechanical support. The connector supports a current rating of 4A and a maximum voltage of 50V, suitable for various electronic and industrial applications.
Operating temperature ranges from -40°C to 105°C, enabling its use in harsh environmental conditions. The unique latch locking system in the DF65 series ensures secure and stable mating with complementary cable mount socket housings.
This connector is ideal for electronics manufacturing, industrial equipment, and communication devices requiring compact, reliable wire-to-board connections. Features a 1-row, 3-contact shrouded header design with 1.7 mm pitch.
Housing material is liquid crystal polymer, providing durability and heat resistance. Brass contact with tin plating offers excellent conductivity and corrosion resistance. Current capacity up to 4A supports demanding electrical requirements.
Surface mount type for easy PCB assembly with solder termination. Operational temperature range of -40°C to 105°C suits industrial conditions. Manufactured in Japan, ensuring high-quality standards. The package contains 1 piece of Hirose DF65 Series Straight Surface PCB Header, model DF65-3P-1.7V(21). For complementary sockets, refer to related Hirose crimp socket housings.
Explore more PCB Headers and connectors in EnvMart's Electronics Components category for all your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Hirose DF65 Series Straight Surface PCB Header supports a maximum current of 4A and a voltage rating of 50V.
It operates reliably between -40°C and 105°C, making it suitable for harsh environmental conditions.
This model features a solder termination type for easy integration onto printed circuit boards.
It has 3 contacts arranged in a single row.
The pitch size of this connector is 1.7 mm.
The housing is made from liquid crystal polymer, and the contacts are brass plated with tin for excellent conductivity.
The tail pin length is 1 mm, enhancing secure soldering and contact.
This model is a shrouded type, which provides additional security for connections.
It is designed and made in Japan, ensuring high-quality standards.
It is ideal for electronics manufacturing, industrial equipment, and communication devices requiring compact, reliable wire-to-board connections.
This PCB header uses a wire-to-board connector system.
The orientation of this model is straight, allowing for easy PCB layout integration.
