TDK-Lambda DC/DC Converter, Surface Mount, 3.3V DC Output, 1.2A, 36V Max Input, 18V Min Input, 6W Power, 85°C CC6-2403SR-E

TDK-Lambda CC6-2403SR-E DC/DC Converter is a high-quality surface mount power supply module designed for reliable voltage conversion applications. This compact unit converts a DC voltage input between 18V and 36V into a regulated 3.3V DC output with current capacity up to 1.2A and power rating of 6W.

Engineered for demanding environments, it operates effectively over a broad temperature range from -40°C to 85°C. The device features robust 500V isolation voltage between input and output to ensure safe operation in electrical systems requiring separation between circuits.

The single-output converter utilizes a surface mount package type with 7 pins, facilitating easy integration on printed circuit boards especially in telecommunications, industrial automation, and consumer electronics where space-saving design is critical.

The overall dimensions include a length of 22.86mm, width of 22.8mm, and depth of 21.1mm. Its lightweight design weighing just 5.8 grams adds negligible mass to assemblies requiring compact power regulation.

Efficiency stands at a notable 0.77%, supporting energy-efficient operation, while the output voltage adjustment range of ±3% allows for fine tuning to meet specific system requirements. The input ratio of 2:1 supports versatility in applications across various input supply conditions.

This DC/DC converter is part of the CC-E series from TDK-Lambda, known for their compact footprint and reliable performance. Applications include telecommunication infrastructure, industrial power supplies, consumer electronic devices, and other fields requiring isolated DC voltage conversion.

The product originates from Japan and is offered as new condition. It does not carry additional certifications or approvals but complies with RoHS directives. Designed for compact applications requiring isolated DC voltage conversion.

Supports input voltages ranging from 18V to 36V. Surface mount package type with 7 pins enhances PCB integration. Operates reliably within temperature range from -40°C to 85°C. Offers 500V input-output isolation for enhanced electrical safety.

Extremely low weight of 5.8 grams ensures minimal load on assemblies. Dimensions approximately 22.86mm length, 22.8mm width, and 21.1mm depth. Efficiency rating of 0.77% suitable for low power industrial and telecommunications equipment.

Single output configuration with adjustable output voltage span of ±3%.
