TDK-Lambda CC-E DC/DC Converter 5V DC 600mA 36-76V Input 6W Surface Mount 7-Pin CC6-4805SR-E
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 5V dc/ 600 mA, 76 |
| Brand | TDK-Lambda |
| Efficiency | 0.81% |
| Length | 22.86mm |
| Model | CC6-4805SR-E |
| Depth | 21.1mm |
| Gross Weight | 5.8g |
| Width | 22.8mm |
| Mount Type | Surface |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 76V |
| Minimum Input Voltage | 36V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 600mA |
| Isolation Voltage | 500V |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Compact surface mount design with 7-pin package.
- Supports input voltages from 36V to 76V for flexible applications.
- Maximum output power of 6 watts with high efficiency.
- Isolation voltage rated at 500 volts for safety.
- Operates between -40 °C and 85 °C to withstand harsh environments.
- Single output delivering 5 volts DC at 600 milliamps.
- RoHS compliant and made in Japan for quality assurance.
- Ideal for telecommunications, industrial equipment, and consumer electronics power conversion.
Product Description
TDK-Lambda CC6-4805SR-E DC/DC Converter is a high-performance isolated DC-DC converter delivering a 5V DC output with 600mA current capability. Designed for surface mount applications, this converter supports a wide input range from 36V to 76V, making it suitable for various industrial and electronic equipment power supply requirements.
With a maximum output power of 6 watts and an isolation voltage of 500V, it ensures electrical safety and reliable operation in complex circuits. The device features a compact footprint measuring 22.86mm in length, 22.8mm in width, and 21.1mm in depth, with a lightweight design weighing only 5.8 grams. Its 7-pin surface mount package facilitates easy PCB integration.
Operating temperature ranges from -40 °C to 85 °C, making it robust for harsh industrial environments. TDK-Lambda’s CC-E series converters are widely used in telecommunications, industrial controls, and consumer electronics, where voltage conversion and isolation are critical.
Compact and lightweight 7-pin surface mount package. Wide input voltage range for versatile applications. Reliable 5V output with 600mA current capacity. High isolation voltage to improve safety in circuits. Efficient operation with 0.81% efficiency rating.
Suitable for industrial, telecommunications, and consumer electronics. Operates reliably within -40 °C to 85 °C temperature range. Manufactured in Japan ensuring premium quality standards. RoHS compliant with no hazardous substances.
Explore a wide range of DC/DC Converters on EnvMart for dependable power solutions in electronic designs and industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for the TDK-Lambda CC6-4805SR-E is from 36V to 76V.
This model delivers a maximum output current of 600mA.
The maximum output power of this DC/DC converter is 6 watts.
The dimensions of the TDK-Lambda CC6-4805SR-E are 22.86mm in length, 22.8mm in width, and 21.1mm in depth.
It operates reliably within a temperature range of -40 °C to 85 °C.
The isolation voltage for the TDK-Lambda CC6-4805SR-E is rated at 500 volts.
This model has an efficiency rating of 0.81%.
The TDK-Lambda CC6-4805SR-E has one output channel.
This converter features a surface mount design.
It is suitable for telecommunications, industrial equipment, and consumer electronics power conversion.
The weight of the TDK-Lambda CC6-4805SR-E is 5.8 grams.
Yes, the TDK-Lambda CC6-4805SR-E is RoHS compliant, indicating it contains no hazardous substances.
