TDK-Lambda CC-E Series DC/DC Converter 5V DC Output 300mA 36V-76V Input 1.5W Through Hole DIP Package CC1R5-4805SF-E

The TDK-Lambda CC1R5-4805SF-E DC/DC Converter is a compact and highly reliable isolated power converter from the CC-E series, designed for converting DC from one voltage level to another safely in various industrial and electronic applications. It delivers a regulated 5V DC output at 300mA current rating with a maximum output power of 1.5W, powered from a wide input voltage range of 36V to 76V DC. The device features a through hole DIP package, allowing easy mounting on printed circuit boards with 7 pins.

Engineered for durability and safety, this converter provides an input-to-output isolation voltage of 500V, which enhances protection and prevents electrical noise transmission between circuits. Its operating ambient temperature range from -40°C to 85°C makes it suitable for harsh environmental conditions common in industrial and telecommunication sectors.

With physical dimensions of 19.81 mm length, 16.5 mm width, and 16.6 mm depth, the CC1R5-4805SF-E offers a compact footprint and weighs only 3.2 grams, contributing to lightweight device design in consumer electronics and industrial equipment. The efficiency of the module is approximately 76%, ensuring effective power conversion with minimal energy loss.

This DC/DC converter is commonly utilized in applications requiring stable low-voltage DC supply derived from higher voltage battery or DC bus levels, including telecom systems, industrial controls, and various electronic consumer products. Its isolated configuration improves electrical safety and noise reduction in complex systems.

Compact footprint with through hole mounting for PCB integration. Input voltage range from 36V to 76V suitable for various DC supply voltages. Single output voltage of 5V DC with 300mA current rating and 1.5W max power. High isolation voltage of 500V enhances circuit safety and reliability.

Operating temperature range from -40°C to 85°C. DIP package dimensions approx. 19.81 mm length, 16.5 mm width, and 16.6 mm depth. Efficiency rated at approximately 76% optimizing power usage. Lightweight design at 3.2 grams ideal for compact electronic systems.

Suitable for telecommunication, industrial, and consumer electronic equipment. 7-pin configuration supports input ratio 2:1 for flexible design.

Choose TDK-Lambda CC-E series DC/DC converters for reliable isolated power supply solutions in demanding industrial, telecommunication, and electrical devices. Explore the EnvMart category for more advanced DC/DC Converters.
