Bourns 5028 Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±30% 1.15 A IDC Q:7 SRR5028
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.8mm |
| Length | 5.8mm |
| Model | SRR5028 |
| Depth | 5.8mm |
| Packaging | Reel |
| Series | SRR5028 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Package/Case | 5028 |
| Maximum DC Current | 1.15A |
| Maximum DC Resistance | 120mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 20MHz |
| Minimum Quality Factor | 7 |
| Inductor Construction | Wirewound |
Key Features
- The inductor uses a wirewound construction with magnetic shielding for improved performance.
- It has a compact 5028 package size with dimensions of 5.8 mm length, 2.8 mm height, and 5.8 mm depth.
- Suitable for surface mount applications in electronic circuits including DC/DC converters and power supplies.
- Operates reliably within a temperature range of -40°C to 125°C.
- Features a maximum DC resistance of 120 mΩ and a minimum quality factor of 7.
- The core material is ferrite, and the inductor is molded for durability.
- Meets RoHS compliance standards and is supplied on a reel for automated assembly.
Product Description
Bourns SRR5028 is a high-quality shielded wirewound surface mount inductor with a ferrite core, providing an inductance of 22 μH ±30% and rated for a maximum DC current of 1.15 A. Its compact 5028 package and low profile make it ideal for densely packed PCB designs in portable communication devices, camcorders, LCD TVs, and car radios.
This inductor series offers magnetic shielding ensuring minimal electromagnetic interference, while the wirewound construction guarantees stable inductance and performance. The component operates effectively over a wide temperature range, from -40°C to 125°C, supporting robust operation in demanding industrial and commercial electronics.
Key product features include a maximum DC resistance of 120 mΩ, a minimum quality factor of 7, and a maximum self-resonant frequency of 20 MHz. The molded ferrite core construction enhances mechanical strength and reduces signal loss.
Supplied on reels, the SRR5028 series inductors facilitate automated SMT assembly, contributing to manufacturing efficiency. Applications span industrial electronics, power supplies, DC/DC converters, and other devices requiring reliable filtering and energy storage.
The inductor's magnetic shielding supports low EMI for sensitive circuits. The wirewound design combined with a ferrite core improves performance and durability. RoHS-compliant manufacturing ensures environmental and safety standards.
Compact footprint ideal for modern electronics with space constraints. Supports a maximum DC current of 1.15 A suitable for moderate power applications. Operating temperature range from -40°C to 125°C ensures versatility in harsh conditions.
Available in a 5028 package supplied on tape and reel for SMT processes. Explore more Surface Mount Inductors and other electronic components at EnvMart for comprehensive industrial, laboratory, and commercial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 22 μH with a tolerance of ±30%.
This inductor has a maximum DC current rating of 1.15 A.
The dimensions of the 5028 package are 5.8 mm in length, 2.8 mm in height, and 5.8 mm in depth.
The maximum DC resistance for this model is 120 mΩ.
It operates reliably within a temperature range of -40°C to 125°C.
The minimum quality factor for this inductor is 7.
The core material used in this model is ferrite.
The wirewound construction guarantees stable inductance and performance, enhancing its reliability in various applications.
This inductor is suitable for applications in DC/DC converters, power supplies, and other electronic circuits requiring reliable filtering and energy storage.
The maximum self-resonant frequency for this model is 20 MHz.
Yes, it meets RoHS compliance standards, ensuring it adheres to environmental and safety regulations.
The SRR5028 is supplied on a reel, facilitating automated SMT assembly.
