Vishay Single Layer Ceramic Capacitor 3.3 nF 1 kV DC ±10 % S3N Dielectric, F Series, Through Hole, 125°C F332K59S3NN63J0R

Vishay F332K59S3NN63J0R Single Layer Ceramic Capacitor is a precision passive component ideal for high-frequency and high voltage DC applications, including switching mode power supplies (SMPS), high-frequency ballast, and snubber circuits.

Constructed with a ceramic disc using S3N dielectric material, this capacitor ensures low losses and high capacitance in a compact size. The capacitor belongs to the Vishay F Series and features through-hole mounting with solderable kinked leads made of tinned copper for reliable connection.

Designed to operate up to 125°C maximum temperature and a nominal voltage rating of 1 kV DC, this capacitor ensures stability and safety in demanding electronic environments. Its tolerance of ±10 % allows for precise filtering and noise suppression.

The dimensions are 40 mm in height, 15 mm in diameter, and 24.5 mm in width, making it suitable for PCB integration where space optimization is required. The dissipation factor is 0.2 %, which denotes excellent efficiency and thermal performance.

The capacitor complies with EC and RoHS standards, ensuring environmental safety and regulatory conformity. The product is not certified to automotive standards.

This capacitor is primarily used in industrial electronics, laboratory instruments, power supply designs, and commercial electrical devices requiring high reliability and low energy loss characteristics.

This capacitor features a through-hole mount type with a ceramic disc package. The rated voltage is 1 kV DC, suitable for high voltage applications. It offers a capacitance of 3.3 nF and a tolerance of ±10 % for precision performance.

S3N dielectric material enhances stability and reliability in SMPS and snubber circuits. Maximum operating temperature is rated at 125°C, providing durability under thermal stress. The capacitor includes kinked silver-plated leads suitable for easy soldering and mounting.

Its dimensions include a height of 40 mm, diameter of 15 mm, and width of 24.5 mm. The dissipation factor is low at 0.2 %, indicating minimal energy loss during operation. Explore our extensive range of Single Layer Ceramic Capacitors at EnvMart for all your electronic component needs.
