Vishay Single Layer Ceramic Capacitor 1 nF 15kV DC Y5U Dielectric Through Hole Radial Lead 615R Series 615R150GAD10

Vishay 615R150GAD10 is a Single Layer Ceramic Capacitor designed for high voltage applications with a capacitance of 1 nF and a DC voltage rating of 15 kV. It features a Y5U dielectric material and a tolerance range of -20 to 80 percent, ensuring stable performance in varied conditions.

This capacitor supports through hole mounting with radial leads made of tinned copper, enhancing ease of installation on printed circuit boards. The ceramic disc is silver plated on both sides and coated with a flame retardant epoxy resin, providing high reliability and resistance to environmental factors.

The maximum operating temperature rating is 105°C, and the device functions effectively at temperatures as low as -25°C. Its dissipation factor is only 2 percent, placing it in Class II suppression, suitable for applications requiring low losses and consistent electrical characteristics.

With physical dimensions of 17 mm diameter and 10.7 mm width, this capacitor is compact yet capable of handling significant power. The capacitor series 615R is well suited for high power and high voltage applications including televisions, monitors, DC and pulse high voltage circuits, X-ray equipment, and switched mode power supplies (SMPS).

Manufactured in the Czech Republic, the Vishay 615R150GAD10 complies with EC and RoHS directives, ensuring environmental safety and regulatory compliance. Features Y5U dielectric with tolerance of -20 to 80 percent. Operates reliably between -25°C to 105°C maximum temperature.

Class II suppression with low dissipation factor of 2 percent ensures high stability. Radial terminal type with two pins and silver-plated ceramic disc construction. Diameter of 17 mm and width of 10.7 mm for compact PCB mounting.

Flame retardant epoxy resin coating enhances safety and durability. Applications include TV, monitors, DC and pulse high voltage, X-ray equipment, and switched mode power supplies. Manufactured in the Czech Republic with compliance to EC and RoHS standards.

This capacitor is ideal for industrial, electronic manufacturing, and high voltage laboratory applications requiring stable and reliable performance. Explore Vishay components and similar capacitors in the Single Layer Ceramic Capacitors category at EnvMart.
