MEAN WELL RPS-120S-15 Switching Power Supply 15V dc, 142.5W, 9.5A Output, PCB Mount, 80-264V AC Input RPS-120S-15

MEAN WELL RPS-120S-15 is a highly reliable, 120W switching power supply with a 15V DC output and 9.5A output current. This PCB mount power supply operates with an input range of 80 to 264VAC, making it suitable for diverse industrial and electronic applications.

The compact footprint measuring 76.2mm length, 28mm width, and 28mm depth allows easy integration into various systems requiring efficient power management. Its operating temperature spans from -30°C to 85°C, providing robust performance in challenging environments.

This power supply attains up to 92% efficiency, reducing thermal stress and power consumption during operation. It is designed with advanced protections including short circuit, overload, over voltage, and over temperature to enhance operational safety and equipment longevity.

The RPS-120S-15 features ultra-low no-load power consumption below 0.3W and minimal leakage current under 150μA, supporting energy efficiency and compliance with stringent safety standards. It is suitable for both Class I and Class II system designs, adaptable to various equipment requirements.

The product conforms to multiple global certifications such as UL 62368-1, CSA C22.2 No. 62368-1, TUV BS EN/EN 62368-1, CCC GB4943.1, and more, ensuring reliability and quality adherence.

Typical applications include industrial machinery, medical devices, automation systems, and telecommunications equipment where stable, efficient power supply is critical.

MEAN WELL's RPS series is recognized for high power density and reliability on a 3 inch by 2 inch form factor, making the RPS-120S-15 an ideal choice for compact and demanding applications.

This switching power supply is proudly manufactured in China and meets international standards for safety and performance. Features a compact 76.2mm x 28mm x 28mm PCB mount design for easy integration. Operating temperature ranges from -30°C to 85°C ensuring robust performance.

High efficiency of 92% reduces energy loss during operation. Provides comprehensive protections including short circuit, overload, over voltage, and over temperature safeguards. Extremely low no-load power consumption of less than 0.3W supports energy saving.

Designed for both Class I (with FG) and Class II (no FG) system designs. Leakage current is minimal at less than 150μA for safety and compliance. Certifications include UL, CSA, TUV, CCC, and others confirming international standards adherence.

Made in China ensuring consistent manufacturing quality. Explore further high-quality power supplies and switching power solutions at EnvMart’s Electronics & Electricals category for reliable industrial and commercial performance.
