RS PRO Analogue Panel Ammeter DC 100 A, 45 mm x 45 mm, 1% Accuracy, Moving Coil 186-2474

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Analogue Panel Ammeter DC 100 A, 45 mm x 45 mm, 1% Accuracy, Moving Coil 186-2474

Name: RS PRO Analogue Panel Ammeter DC 100 A, 45 mm x 45 mm, 1% Accuracy, Moving Coil 186-2474
Brand: RS PRO
SKU: 101597
Price: 40.46 USD
Availability: InStock



Category Panel Meter Brand RS PRO Condition New

Specifications

Country of Origin	India
Relative Humidity	Less than 75% annual average (noncondensing)
Brand	RS PRO
Model	186-2474
Depth	54mm
Series	RS PRO
Maximum Operating Temperature	65°C
Current Type	DC
Pointer	Knife-edge type
Meter Accuracy	1 %
Minimum Operating Temperature	-10°C
Shock Resistance	15g for pulse duration of 11 milliseconds
Overload	1.2 times nominal current (continuous)
Standards/Approvals	IEC51/DINEN60051, DIN 43718, IEC 529, VDE 0100-410:2018-10, IEC 51, 2014/30/EC, DIN 43701, DIN 43802, VDE / VDI 3540, ISO 20653:2006-08, DIN 43807, DIN 46200/46282, DIN EN 60051, 93/68/EEC, IEC 61010, EN 61010, UL 94 V-0, DIN IEC 61554, 2014/35/EC
Cutout Height	45mm
Cutout Width	45mm
Maximum Measurement	600 V dc, 1000 V ac
Moving Element	Moving Coil
Maximum Ampere Value	100 A
Pointer deflection	0° to 90°
VDE 0100-410	2018-10 approved
ISO 20653	2006-08
Standards/ApprovalsIEC51/DINEN60051, DIN 43718, IEC 529, VDE 0100-410	2018-10, IEC 51, 2014/30/EC, DIN 43701, DIN 43802, VDE / VDI 3540, ISO 20653:2006-08, DIN 43807, DIN 46200/46282, DIN EN 60051, 93/68/EEC, IEC 61010, EN 61010, UL 94 V-0, DIN IEC 61554, 2014/35/EC
DC Ammeter nominal range	15uA to 100A

Key Features

Designed for DC current measurement up to 100 A.
Operating temperature range from -10°C to 65°C ensures reliable performance.
Knife-edge type pointer with 0° to 90° deflection for precise readings.
Moulded polycarbonate square case suitable for panel mounting.
Meter accuracy of 1% with shock resistance up to 15g for 11 ms pulse duration.
Supports overload up to 1.2 times nominal current continuously.
Complies with IEC51, DIN, VDE, ISO, UL and CE standards.
Rated IP52 for protection against dust and dripping water.

Product Description

RS PRO 186-2474 analogue panel ammeter is a high precision instrument designed for accurate DC current measurement up to 100 A. The device has a compact footprint with a 45 mm by 45 mm cut-out size and a 54 mm depth, making it ideal for integration into control panels and machinery consoles. The moving coil mechanism offers a linear scale with 1% accuracy and a knife-edge pointer that swings from 0° to 90°, ensuring easy and precise monitoring.

This ammeter operates reliably within a wide temperature range of -10°C to 65°C and exhibits robust shock resistance of 15g for short pulses, safeguarding it in demanding industrial environments. The molded polycarbonate square case provides durability and simplifies mounting within switchgear panels. Overload protection enables operation up to 1.2 times the nominal current continuously, while the device maintains performance under relative humidity less than 75% (non-condensing).

The meter complies with numerous international standards such as IEC 51, DIN 43718, IEC 61010, VDE 0100-410, and is CE certified. It carries an IP52 rating, granting moderate protection against dust and water ingress. Typical industries using this ammeter include electrical panel building, industrial automation, process control, manufacturing, and laboratory instrumentation.

Operates on DC current with nominal range from 15 μA to 100 A. High accuracy of 1% enhances measurement reliability. Robust construction with moulded polycarbonate housing. Compatible with international standards for quality and safety.

Designed for installation into 45 x 45 mm panel cutouts. Shock resistant and overload tolerant for industrial use. IP52 rated for protection against dust and water. Supports multiple industrial applications including HVAC, manufacturing, and electrical control panels.
