RS PRO Analogue Panel Ammeter 100 A DC, 68 mm x 68 mm, 1% Accuracy Moving Coil 186-2490

RS PRO 186-2490 is a high-quality Analogue Panel Ammeter designed for DC current measurement up to 100 A, featuring a robust moving coil mechanism for precise readings with 1% accuracy. It is engineered to fit a 68 mm x 68 mm panel cutout, making it ideal for integration into industrial control panels and automation systems.

The instrument has an operating temperature range from -10°C to 65°C, allowing reliable performance in diverse industrial environments. It uses a knife-edge pointer deflecting from 0° to 90°, providing clear and accurate current indication. The meter's shock resistance rating of 15g offers resilience against sudden mechanical shocks and vibrations in harsh settings.

Housed in a moulded square polycarbonate case, this panel ammeter ensures durability and ease of mounting in machinery consoles and switchgear panels. It can handle continuous overloads up to 1.2 times the nominal voltage, ensuring longevity under demanding conditions.

The device features linear calibrated scales allowing accurate average value readings of DC current. It operates with permanent magnet moving coil movements including magnet, aluminium coil, hairspring, and jewel mechanism for steady measurement precision.

Environmental robustness is enhanced by a relative humidity tolerance of less than 75% annual average, preventing condensation and moisture damage. The meter complies with various international standards and certifications including DIN 43718, IEC 61010, VDE 0100-410, UL 94 V-0, and others, ensuring industrial safety and conformity.

This ammeter is suited for industrial, manufacturing, laboratory, and commercial electrical control applications requiring reliable DC current monitoring with high accuracy and durable construction.

The ammeter features a 68 mm x 68 mm cutout suitable for panel mounting. Operating temperature range is from -10°C to 65°C ensuring reliability in varied environments. Knife-edge type pointer offers clear indication with a deflection range of 0° to 90°.

Shock resistance up to 15g protects the meter against pulse impacts lasting 11 milliseconds. Moulded polycarbonate square case supports secure installation in control or switchgear panels. Overload capacity extends to 1.2 times nominal voltage continuously, enhancing durability.

Designed to measure DC currents up to 100 A with linear calibrated scales and average value indication. Relative humidity tolerance below 75% annual average prevents moisture-related failures. Series includes compliance to multiple international standards including DIN 43718, IEC 61010, and VDE regulations.
