RS PRO Analogue Panel Ammeter 100 A DC, 92 mm x 92 mm Cutout, 1% Meter Accuracy 186-2506

RS PRO 186-2506 Analogue Panel Ammeter is a high-precision industrial measurement instrument designed for DC current detection up to 100 A. Featuring a compact 92 mm by 92 mm panel cutout and a depth of 67 mm, it is suitable for mounting in control and switchgear panels within manufacturing, automation, and electrical applications.

The instrument employs a moving coil mechanism comprising a permanent magnet, an aluminium coil suspended on pivots, a hairspring, and a jewel mechanism for smooth and accurate pointer movements. It offers 1% accuracy, which makes it ideal for precise current monitoring in industrial environments.

This ammeter pointer is of the knife-edge type with a deflection range of 0° to 90°, enabling clear, easy-to-read analog indications. Its robust construction, including a moulded polycarbonate case, makes it resistant to shocks of up to 15g for pulses of 11 milliseconds and ensures reliable operation within a temperature range of -10°C to 65°C.

Designed with overload protection at 1.2 times nominal voltage, the device ensures operational safety during transient load conditions. It maintains less than 75% relative humidity in non-condensing environments, further extending its reliability in diverse industrial settings.

The 186-2506 model complies with an extensive list of international standards and certifications, such as DIN 43807, IEC 61010, VDE 0100-410:2018-10, UL 94 V-0, and EMC directives (2014/30/EC), ensuring it meets rigorous quality and safety requirements.

This ammeter is ideal for use in industrial automation systems, electrical panels, process control, and manufacturing plants where dependable current measurement is critical. Its precise measurement capability supports efficient system monitoring and control, enhancing operational safety and performance.

Utilizes a moving coil as the moving element for precise current measurement. Operates reliably between temperatures of -10°C and 65°C. Compact design with 67 mm depth fits standard control and switchgear panels. Offers knife-edge type pointer with deflection from 0° to 90° for clear readings.

Features shock resistance up to 15g for short pulses ensuring durability. Overload capacity is 1.2 times nominal voltage continuously for operational safety. Constructed with a moulded polycarbonate square case providing robust protection.

Suitable for industrial use with compliance to multiple international standards and IEC directives.
