Global Laser Red Modulating Laser Module 650 nm 1 mW PWM Control 5.25V 1421-24-000

Global Laser 1421-24-000 laser module is a high-efficiency red modulating laser emitting at 650 nm wavelength with 1 mW optical output power. Designed for precise beam control, it incorporates PWM digital modulation and operates optimally at 5.25 V supply voltage. With a compact form factor measuring 47.5 mm in length and 15 mm diameter, this laser module provides excellent pointing accuracy below 1 milliradian.

This laser module is built with internal driver circuitry which offers reverse polarity protection and an electrically isolated case for enhanced safety and performance stability. It supports a dot emission pattern ideal for alignment, graphics displays, telemetry systems, and certain medical applications requiring precise optical output control.

Capable of operating reliably within a temperature range of -10°C to 50°C, the 1421-24-000 module aligns with laser class 2 safety standards compliant with BS (EN) 60825 emission criteria. The laser is manufactured in the United Kingdom under the Acculase series, known for precision beam alignment making installation straightforward.

This laser module uses PWM control for output intensity regulation. The 650 nm red laser provides a focused dot emission pattern. Compact dimensions: 47.5 mm length and 15 mm diameter enhance integration ease. Power requirements fixed at 5.25 V supply voltage.

Protective internal driver circuitry prevents damage from reverse polarity. Safe, electrically isolated case construction ensures performance stability. Wide operating temperature range from -10°C to +50°C. Applications include graphics, alignment, telemetry, and medical fields.

This precision laser module is suitable for industrial, laboratory, medical, and manufacturing use cases where high pointing accuracy and output modulation are required. Explore more high-quality Laser Modules from Global Laser in EnvMart’s Electronics Components category for advanced optoelectronic systems.
