Global Laser Red Continuous Wave Laser Module with Ellipse Emission Pattern 670 nm 3 mW 4.5-5.5V 1250-35-000

Global Laser 1250-35-000 is a professional-grade continuous wave laser module that emits red laser light at a wavelength of 670 nm with an optical output power of 3 mW. Designed in the United Kingdom, this laser module belongs to the Cameo industrial laser series and features an isolated metal case with an M12 threaded mount, facilitating secure and precise installation in various industrial environments.

The device's compact size, measuring 24 mm in diameter and 14 mm in length, enables integration into applications requiring minimal footprint. It delivers an elliptical emission pattern with a spot size of less than 50 microns and a low divergence of less than 0.5 mRad, ensuring focused and precise laser output suitable for tasks that demand accuracy.

Engineered for durability, the laser operates efficiently within a temperature range of -10°C to 50°C and is capable of continuous cool running without degradation of performance. The unit operates at a supply voltage between 4.5 and 5.5 V and includes a JST 2-way connector, simplifying power and control connections.

Complying with the BS (EN) 60825 standard, this Class 3R laser module prioritizes safety while delivering high performance. It is ideal for use in industrial processing, laboratory instrumentation, measurement systems, and other commercial applications that require reliable red laser illumination with a compact form factor.

Operates at a supply voltage range of 4.5 to 5.5 volts. Industrial metal isolated casing with M12 thread for simple mounting. Compact dimensions of 24 mm diameter and 14 mm length. Spot size less than 50 microns with low beam divergence under 0.5 mRad.

Designed for continuous cool running across temperatures from -10°C to 50°C. Equipped with JST 2-way connector for easy integration. Complies with BS (EN) 60825 safety standards as a Class 3R laser. Ideal for industrial and laboratory applications requiring precision red laser emission.

This laser module is part of the Cameo series, specifically designed for industrial use with threaded mounting and user focusability. Whether for alignment, measurement, or as a component in complex optical systems, the Global Laser 1250-35-000 offers consistent and safe laser output.
