Vishay Single Layer Ceramic Capacitor 4.7 nF 1kV DC ±10% Y5R Dielectric Through Hole Radial Lead F Series F472K75Y5RN83K0R

Vishay F472K75Y5RN83K0R is a single layer ceramic capacitor designed for demanding electronic applications requiring reliable high-voltage performance and stable capacitance. This capacitor has a capacitance of 4.7 nF paired with a voltage rating of 1kV DC and a tolerance of ±10%, using Y5R dielectric material that offers moderate temperature stability suitable for many industrial and consumer electronics.

The component uses a through-hole mount type with radial terminal leads, packaged as a compact disc with dimensions of 19 mm length, 19 mm diameter, 4.5 mm width, and 32 mm height. It is built to endure maximum operating temperatures of up to 125°C, making it fit for applications exposed to elevated heat conditions.

Compliant with major international standards including IEC 60384-14, RoHS, CSA, and DIN EN 60384-14, this capacitor meets environmental and safety requirements. It exhibits a low dissipation factor of 0.2%, ensuring minimal energy loss during operation, which is critical for high-frequency circuits and power electronics.

Ideal use cases for the Vishay F472K75Y5RN83K0R include switched-mode power supplies (SMPS), high-frequency ballast circuits, snubber circuits, and other high-voltage electronic systems that require stable and reliable capacitance with tight tolerances and moderate temperature coefficients.

This capacitor is not recommended for mains suppression but excels in various industrial, laboratory, and commercial electronic applications where durability and electrical stability are paramount.

This capacitor features a through-hole mount type with radial leads for easy PCB installation. Constructed with a disc package/case and designed to withstand up to 125°C maximum operating temperature. Suitable for electronic circuits requiring low losses and high capacitance in compact sizes.

Complies with IEC 60384-14, RoHS, CSA, and DIN EN 60384-14 standards ensuring quality and safety. Ideal for switched-mode power supplies (SMPS), high-frequency ballasts, and snubber circuits applications. Features a dissipation factor of 0.2% and operates reliably down to a minimum temperature of -30°C.

Pin count is 2 with dimensions: length 19 mm, diameter 19 mm, width 4.5 mm, and height 32 mm, facilitating integration into various electronic assemblies. Explore high-quality capacitors and electronic components in the Single Layer Ceramic Capacitors category at EnvMart for your industrial, construction, and manufacturing needs.
