HARWIN Datamate J-Tek Series Right Angle Through Hole PCB Header 10 Contacts 2 mm Pitch 2 Row Shrouded M80-5401042

HARWIN M80-5401042 Datamate J-Tek Series Right Angle Through Hole PCB Header is a high-performance connector designed for electronic and industrial applications requiring secure and reliable electrical connections. Featuring 10 male contacts with a 2 mm pitch arranged in a 2-row configuration, this shrouded connector is ideal for both board-to-board and wire-to-board systems.

The housing is manufactured from durable polyphenylene sulphide, providing excellent mechanical strength and chemical resistance. The contacts are made of phosphor bronze and plated with gold to offer superior conductivity and corrosion resistance, enhancing long-term reliability.

This connector supports a continuous current rating of 3 Amps and is rated for operation within a wide temperature range from -55°C to 125°C, making it suitable for harsh environmental conditions including industrial, automotive, and aerospace settings. The right angle orientation facilitates compact PCB designs and efficient space utilization.

The through-hole mount type with 3 mm long tail pins ensures strong mechanical retention during soldering. The shrouded design includes polarised mouldings that prevent incorrect mating and improve overall connection integrity. The J-Tek Datamate Series connectors conform to recognized standards such as BS9525-F0033, MIL C 55302, and CEC 75101-008, guaranteeing compatibility and quality.

Manufactured in the United Kingdom, these connectors are engineered for applications where durability and safety are paramount, including industrial machinery, communications equipment, and other demanding electronic assemblies.

Supports 10 contacts with 2 mm pitch in a 2-row configuration. Durable polyphenylene sulphide housing for extended service life. Gold-plated phosphor bronze contacts ensure high conductivity and corrosion resistance. Rated current of 3A ideal for demanding electrical loads.

Operates reliably under operating temperatures from -55°C to 125°C. Right angle design optimizes PCB layout space. Shrouded with polarised moulding to prevent incorrect mating. Through-hole mount with 3 mm tail pins for secure soldering.

Complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards. Produced in the United Kingdom ensuring high manufacturing standards. Explore more in our Electronics Components category to find complementary connectors and PCB accessories from top brands like HARWIN.
