Recom RFMM DC/DC Converter 5V DC Output 200mA 5.5V DC Max Input 1W Through Hole RFMM-0505S
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters Recom RFMM DC/DC Converter, 5V dc/ 200 mA, 5 |
| Brand | Recom |
| Efficiency | 80% |
| Length | 19.65mm |
| Model | RFMM-0505S |
| Depth | 10.2mm |
| Width | 7.05mm |
| Mount Type | Through Hole |
| Series | RFMM |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-7 |
| Minimum Operating Temperature | -40°C |
| MTBF | 13200000h |
| Number of outputs | 1 |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 5.5V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 200mA |
| Isolation Voltage | 4kV dc |
Key Features
- Compact SIP-7 package with through hole mounting for durable PCB installation.
- Isolation voltage up to 4kV DC protects circuits from voltage spikes.
- Wide operating temperature range from -40°C to +85°C for harsh environments.
- High efficiency up to 80% ensures low power loss and heat generation.
- 7-pin configuration designed for reliable electronic applications.
- Compact dimensions of 19.65mm length, 7.05mm width, and 10.2mm depth.
- Mean time between failures (MTBF) rated at 13,200,000 hours for long life.
- Suitable for medical and telecommunication equipment requiring regulated DC power.
Product Description
Recom RFMM-0505S DC/DC Converter is a highly efficient power supply module designed for converting DC input voltages between 4.5V and 5.5V into a stable 5V DC output at 200mA current capacity, delivering up to 1 watt of power. This converter uses a SIP-7 package and through-hole mounting technology for secure and permanent PCB integration.
The module provides an isolation voltage of 4kV DC, effectively protecting connected circuits from voltage spikes and surges. Its compact form factor, measuring 19.65mm in length, 7.05mm in width, and 10.2mm in depth, allows installation in tight spaces, while the non-conductive plastic housing promotes user safety during handling and assembly.
It features high reliability with a mean time between failures (MTBF) of 13.2 million hours, making it ideal for demanding industrial environments. The converter operates efficiently at 80%, minimizing energy waste and heat output.
This DC/DC converter is suitable for various industrial and commercial applications, including medical devices, telecommunication equipment, and other small electronic systems that require a regulated 5V DC power supply from a low voltage DC source. Its wide operating temperature range from -40°C to +85°C ensures robust performance even under extreme environmental conditions.
Compact SIP-7 package with through-hole mounting for secure PCB integration. 4kV DC isolation voltage for protection against voltage surges. Stable 5V output at 200mA current with 1W power rating. High efficiency of 80% reduces power losses.
Wide operating temperature range from -40°C to +85°C. Non-conductive plastic housing ensures safe operation. Dimensions: 19.65 x 7.05 x 10.2 mm suitable for compact designs. MTBF of 13,200,000 hours ensures long-lasting reliability.
Designed for medical and telecommunication applications. Explore the Recom range of DC/DC Converters on EnvMart for reliable power conversion solutions tailored to industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a stable output voltage of 5V DC with a current capacity of 200mA.
The maximum input voltage for the RFMM-0505S is 5.5V DC.
It operates with an efficiency of up to 80%, which helps minimize power loss and heat generation.
The dimensions of this unit are 19.65mm in length, 7.05mm in width, and 10.2mm in depth.
The RFMM-0505S features an isolation voltage of 4kV DC, protecting circuits from voltage spikes.
It can operate in a wide temperature range from -40°C to +85°C, suitable for harsh environments.
This converter uses through-hole mounting technology for secure and permanent PCB integration.
The MTBF for the RFMM-0505S is rated at 13,200,000 hours, indicating high reliability.
This model has one output for delivering regulated DC power.
It is designed for various applications, including medical devices and telecommunication equipment that require regulated 5V DC power.
The minimum input voltage for the RFMM-0505S is 4.5V DC.
This converter is packaged in a compact SIP-7 configuration, suitable for tight spaces.
